Slant Bed CNC Lathe Automatic Turret Machine for Metal Turning Milling

Product Description

Hard Metals and Alloys Processing Affordable Precision CNC Slant Bed Milling Turning Lathe Machine
Product Description

Processing Capability			Unit	RA-1000M
Processing Capability	Maximum bed swivel diameter		mm	Φ630
	Maximum machining diameter		mm	Φ580
	Maximum machining diameter on the tool holder		mm	Φ370
	Maximum processing length		mm	950
	Maximum bar through-hole diameter		mm	Φ72
Machining dimensions will change with turret selection.
Spindle	Nose of spindle		ASA	A2-8
	Spindle through-hole diameter		mm	Φ87
	Maximum spindle speed		rpm	2500
	Hydraulic cylinders/chucks		Inch	10''
Axis feed	Axis travel	X-Axis	mm	370
		Z-Axis	mm	1120
	Travel Speed	X-Axis	mm	15
		Z-Axis	mm	20
	Rail Type		/	Linear track 45 (ball)
Turret	Number of tool positions		pcs	BMT55-12T
	OD tool holder specifications		mm	25x25
	I.D. Tool Holder Specifications		mm	Φ40
Tailstock	Hard rail as standard		/	Z-axis driven
	Maximum travel of tailstock rail		mm	1250
	Tailstock Sleeve Taper		mm	Morse #5
	Tailstock Sleeve Diameter		mm	Φ100
	Tailstock sleeve travel		mm	120

Optional accessories:

Oil-water separator

Oil Mist Absorber

Fully automatic feeding machine

Electric cabinet air conditioner

Rotatable window

Workpiece probes

High pressure water pumps

Chip conveyor

Tool setting arm

Detailed Photos
Control System
Anoher Advantages
• Experience the ultimate in processing with our state-of-the-art production facilities, designed to deliver optimal performance and superior results.
Our cutting-edge imported equipment-including horizontal and vertical machining centers, CNC boring machines with rotating tables, and gantry guideway grinding machines-ensures exceptional precision in every workpiece. This significantly enhances assembly accuracy and extends performance longevity.
• State-of-the-Art Detection Methods
Positioning accuracy is rigorously tested and precisely calibrated using advanced laser technology, strictly adhering to the stringent German VDI3411 inspection standards, with a comprehensive 5-test protocol.
Each machine tool undergoes stringent processing tests before leaving our factory, ensuring they not only meet but often exceed actual processing accuracy standards.
Product sample
• Experience unparalleled efficiency with our Automated 4-Axis CNC Drilling Milling Center. This advanced machine seamlessly integrates milling, drilling, and tapping functionalities, setting new standards in productivity and precision. Discover the pinnacle of vertical machining excellence.
• Master the art of precision with our CNC machine, meticulously engineered to handle a wide array of materials, from aluminum and steel to copper and non-metal profiles. Achieve unmatched craftsmanship and meticulous detail in every project with this expertly designed machinery.
• Elevate your production capabilities across diverse industries, including 3C electronics, rail transportation, aerospace, and linear module guide rails, with our versatile CNC machining solutions. Our cutting-edge technology delivers unmatched versatility and performance, ensuring your operations reach new heights.
Packaging & Shipping
•Highly Protective: Our packaging solutions are meticulously engineered to ensure that the Vertical CNC Drilling Machine Center remains safe and secure throughout its journey. With robust protection, we safeguard against any potential damage, ensuring peace of mind and product integrity.
•Structural Stability: Our packaging is thoughtfully designed to uphold the machine's structural integrity. Each component is securely protected, guaranteeing that the machine arrives in pristine condition and is ready for immediate, hassle-free operation.
•Environmentally Friendly and Recyclable: Embracing our commitment to sustainability, we utilize packaging materials that are both durable and eco-friendly. Our fully recyclable solutions minimize environmental impact, harmonizing robust protection with responsible stewardship of our planet.
Professional Team
FAQ
1. What are the Payment Terms?
A: We accept T/T payments, requiring a 40% initial deposit upon ordering and the remaining 60% balance to be paid before shipment. This ensures a seamless transaction process.
2. What are your trade terms?
A: We offer comprehensive trade terms including FOB, CFR, and CIF. This flexibility allows you to choose the most convenient terms according to your needs.
3. When is the delivery time?
A: For our standard Vertical CNC Drilling Machine Center, we guarantee delivery within 30 days. Custom or specialized machines may require additional time, so please align your orders with our detailed delivery schedule.
4. What is your minimum order quantity and warranty?
A: We require a minimum order of just one set and proudly offer a comprehensive one-year warranty to ensure your complete satisfaction.
5. How are the machines packaged?
A: Each machine is meticulously encased in a robust wooden box, ensuring it arrives at your location in pristine condition.
6. How can I choose the most suitable machines?
A: Simply share your specifications with us, and we will recommend the most suitable model tailored to your needs. Alternatively, you can select a model based on your own preferences.
Additionally, you can send us your product drawings, and our experts will identify the ideal machine configuration for you, ensuring optimal performance.

---
