One Piece Body Wafer Dual Plate Check Valve

Product Description

The function of Wafer Dual Plate Check Valve is to only allow the medium to flow in one direction and prevent the flow in the opposite direction. Usually, this type of valve works automatically, and under the pressure of fluid flowing in one direction, the valve disc opens; When the fluid flows in the opposite direction, the pressure of the fluid and the self weight of the valve disc act on the valve seat, thereby cutting off the flow.
Wafer Type Check Valve Specification Size:2"~30"(DN 50~DN 750)
Pressure:Class 150~Class 2500
End connection:RF,RTJ,FF,Wafer,Lug

Main material Casting Steel:WCB,WCC,WC6,WC9,LCB,LCC,CF8,CF3,CF8M,CF3M,CF8C,4A,5A,6A,CN7M,CW6MC,
CW12MW,CU5MCuC,C5,C12,M35-1
Special Alloy Steel:Inconel,Hastelloy,Monel

Wafer Type Check Valve Standard and Features Std:
1.Design & manufacture:API 6D,API 594
2.Flange END:ASME B16.5
3.Face To Face :ASME B16.10
4.Pressure-temperature rating:ASME B16.34
5.Butt END:ASME B16.25
6.Inspection & Test:API 598
7.Also available per NACE MR 0175,NACE MR 0103

Feature:
1. One Piece Body
2. Butterfly Swing Type
3. Dual-plate Disc,Long-pattern
4. Renewable Split Disc
5. Non-penetrate disc shaft
6. Horizontal or vertical service
7. Available With Flanged or Lug Type
8. The product has reasonable structure, reliable sealing, excellent performance and beautiful design.
9. Easy to disassemble and maintain.
10. Unidirectional sealing to prevent medium backflow.

---
