US$3.00
1,000-9,999 Pieces
Basic Info.
Uniformity(Max.)(dB)
1.0/1.2
Adapter Type and Count
Sc/APC
Name
FTTH Optical Mini Type Splitter 1X2 Bare Fiber Opt
Production Capacity
5000PCS Per Month
Packaging & Delivery
Package Size
42.00cm * 42.00cm * 35.00cm
Package Gross Weight
7.000kg
Product Description
FTTH Optical Mini Type Splitter 1X2 Bare Fiber Optic PLC Splitter
Description Low insertion loss, Low PDL and High reliability Excellent Environmental & Mechanical Stability Multi-way cost is low, the more roads, the more obvious cost advantage. Excellent channel-to-channel uniformity Qualified Under Telcordia GR-1221 and GR-1209 Product Applications LAN, WAN and Metro Networks FTTH project & FTTX Deployments CATV System GPON, EPON Fiber Optic Test Equipment Data-base Transmit Broadband Net Technical Parameter
Product Type | 1×2/2x2 | 1×4/2x4 | 1×8/2x8 | 1×16/2x16 | 1×32/2x32 | 1×64/2x64 | 1×128/2x128 |
Wavelength(nm) | 1260~1650 |
I.L(dB) | Typ. | 3.6/4.2 | 7.1/7.2 | 10.4/10.6 | 13.6/13.8 | 17.2/17.5 | 20.1/20.5 | 25.0/25.2 |
Max. | 4.3/4.5 | 7.4/7.6 | 10.7/11.0 | 14.0/14.8 | 18.0/18.0 | 21.5/21.5 | 25.8/25.8 |
Uniformity(Max.)(dB) | 0.5/0.8 | 0.8/1.0 | 1.0/1.2 | 1.4/1.5 | 1.6/1.8 | 2.0/2.5 | 2.6/3.0 |
PDL(Max.)(dB) | 0.2/0.2 | 0.3/0.3 | 0.3/0.3 | 0.3/0.3 | 0.3/03 | 0.5/0.5 | 0.8/1.0 |
TDL(Max.)(dB) | 0.5 |
R.L(dB) | ≥55(APC)/≥55(UPC) |
Directivity(dB) | ≥55 |
Operating & Storage | -40~+85 |
Temperature |
Note: All the data above does not include connectors. |
UPC Connectors: IL add 0.2 dB, APC Connectors: IL add 0.3 dB. |
Fiber optical Characteristic (after cable)
Fiber type | Attenuation | Bandwidth | Effective modal bandwidth | 10 Gb/s Link Length |
Conditions | 1310/1550nm | 850/1300nm | 850/ | 850nm | 850nm |
Typical | Maximum | Typical | Maximum | 1300nm |
Unit | dB/km | dB/km | dB/km | dB/km | MHz.km | MHz.km | m |
G652D | 0.5/0.4 | 0.6/0.5 | / | / | / | / | / |
G657A1 | 0.5/0.4 | 0.6/0.5 | / | / | / | / | / |
G657A2 | 0.4/0.3 | 0.5/0.4 | / | / | / | / | / |
G657B3 | 0.5/0.4 | 0.6/0.5 | / | / | / | / | / |
62.5/125 | / | / | 3.5/1.0 | 3.5/1.5 | ≥160/500 | / | / |
50/125/ | / | / | 3.0/1.0 | 3.5/1.5 | ≥200/500 | / | / |
OM1 |
50/125/ | / | / | 3.0/1.0 | 3.5/1.5 | ≥500/500 | / | / |
OM2 |
OM3-150 | / | / | 3.0/1.0 | 3.5/1.5 | ≥700/500 | ≥950 | 150 |
OM3-300 | / | / | 2.5/0.8 | 3.0/1.0 | ≥1500/500 | ≥2000 | 300 |
OM4-550 | / | / | 2.5/0.8 | 3.0/1.0 | ≥3500/500 | ≥4700 | 550 |
Package
FAQ
1. Can I visit you?
-Sure,our factory is in Shenzhen ,China. Kindly contact us to make an appointment.
2. How long is your delivery time?
-Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. What is your payment terms?
-Payment<=3000USD, 100% in advance. Payment>=3000USD, 30% T/T in advance ,balance before shippment.
4. How about the warranty?
-There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands.
5. Can you produce according to the samples?
-Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
>>
