Product Details
Product Description
Product Description
Brand:ABSOLUTE
Type:API4380G
Origin: the United States
Warranty: 365 days
Colour: new/used
Shipping method: Courier delivery
Spare parts spare parts, the main DCS control system of PLC system and the robot system spare parts,
Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts
CI857 and TP853 – INSUM Interface Key Features • Provides one Ethernet port, (RJ45 connector located on the TP853 Baseplate). Only COM1 is used for INSUM. • Simple DIN-rail mounting • Provides communication with INSUM via Ethernet/LON Gateway • Pre-set, two-letter Alpha code locking device installed in unit base prevents mounting of incompatible components. • Supports Hot swap. Description The CI857/TP853 can be used to connect an AC 800M controller to INSUM through TCP/IP over Ethernet and an INSUM TCP/IP Gateway that has a LON interface communicating with the underlying INSUM system. The TP853 Baseplate has two RJ45 Ethernet connectors, though only the COM1connector is used for connecting to INSUM. The baseplate has a code lock, see Table 4 on page 75, that prevents the installation of an incorrect type of unit onto the TP853 Baseplate. The CI857 expansion unit contains the CEX-Bus logic, a communication unit and a DC/DC converter that supplies appropriate voltages from the +24 V supply via the CEX-Bus. The Ethernet cable must be connected to the main network through an Ethernet Switch.
Unit error detected. Controlled by Control Software. Set and cleared by the Hardware during controller Reset. R(un) /Green Operating. Controlled by the Control Software. Cleared by the Hardware during controller Reset. Tx1 /Yellow flashing A yellow LED indicating transmission from the communication unit COM1 port. Rx1 /Yellow flashing A yellow LED flashes when data is being received from the COM1 port. Tx2 OFF Not used. Rx2 OFF Not used. Table 89. CI857 INSUM Interface Specifications Item Value Type Ethernet unit. Protocol INSUM TCP/IP Communication speed 10 Mbit/s (half duplex) Status indicators Running normally: Green. Exceptional fault: Red. Two traffic indictors - Tx1/Rx1 - controlled by traffic pace: Flashing yellow. Connector 2 RJ45 (only COM1 is used).
>>
