Customizable Hydraulic Oil Cylinder Testing Jack for Pile Foundation Inspection Sedimentation Test Static Press Piling

Product Description

YXRG series pile foundation inspection hydraulic cylinder is double acting, large tonnage, oil pressure return, this advanced product is developed especially for the industries of foundation settlement test, static pile loading, pile foundation inspection, and so on. It adopts special seal structure, has high strength cylinder block, so it has the characters of good pressure maintaining, high safety factor, long lift etc.
Can be customized by your requirement.

Model	Tonnage (T)	Bore Diam (mm) E	Out Diam (mm) D	Rad Diam (mm) F	Stroke (mm) L	Coll Height (mm) A	Extende Height (mm)	Rated Pressure (Mpa)	Weight (kg)
YXRG200-200	200	200	273	150	200	400	600	63	130
YXRG200-250					250	450	700		145
YXRG320-200	320	250	325	180	200	435	635	63	215
YXRG320-250					250	485	735		240
YXRG400-200	400	280	377	200	200	465	665	63	300
YXRG400-250					250	515	765		330
YXRG500-200	500	320	426	250	200	488	688	63	436
YXRG500-250					250	538	788		482
YXRG630-200	630	360	490	280	200	536	736	63	693
YXRG630-250					250	586	836		751
YXRG800-200	800	400	550	320	200	585	785	63	974
YXRG800-250					250	635	885		1035
YXRG1000-200	1000	450	610	360	200	620	820	63	1337
YXRG1000-250					250	670	920		1430
YXRG1200-200	1200	500	670	380	200	640	840	63	1647
YXRG1200-250					250	690	940		1752

---
