R32 R290 Air Source Heat Pump 11-34kw CE a+++ DC Inverter Heat Pump Monoblock Water Heater Warmepumpe

Product Description

Product Description
Mango Heat Pump QII PRO Series split DC Inverter Heat Pump with wifi R321.R32 Refrigerant pipe connection for best system stability even in tough weather.
2.E-heater, diverter valve,water pump,and expansion tank can be included
3.A+++ Energy Rating Level,with CE,TUV test report.
4.Low noise sound power level as low as 52dB(A)
5.Work down to -30 degree C
6.WIFI solution available,Carel controller. 7.Function: Heating +Cooling+ Hot water

Model				MGSDC-030IIC	MGSDC-050IIC	MGSDC-060IIC	MGSDC-080IIC	MGSDC-100IIC
HP				3HP	5HP	6HP	8HP	10HP
Ambient	Outlet	Power Supply		220-240V / 50-60Hz / 1ph or 380-415V / 50-60Hz / 3ph				380-415V / 50-60Hz / 3ph
+7°C	35°C	Heating Capacity	kW	9.25	15.34	18.65	23.28	30.90
		Power Input	kW	2.11	3.36	4.16	5.12	6.78
COP				4.38	4.57	4.48	4.55	4.56
-7°C	40°C	Heating Capacity	kW	7.80	13.22	16.11	19.84	26.30
		Power Input	kW	2.79	4.59	5.57	6.91	9.13
COP				2.8	2.88	2.89	2.87	2.88
-15°C	40°C	Heating Capacity	kW	6.75	10.51	12.25	15.77	21.20
		Power Input	kW	2.81	4.29	5.00	6.52	8.72
COP				2.40	2.45	2.45	2.42	2.43
+35°C	7°C	Cooling outlet	kW	7.62	13.18	16.21	20.51	23.80
		Power Input	kW	2.61	4.51	5.59	7.15	8.32
EER				2.92	2.92	2.90	2.87	2.86
Work Ambient			°C	-30°C - 43°C
Outlet Water Temperature			°C	5°C - 55°C (70°C R290)
Control System				XITA or CAREL (Advance)
Compressor				Panasonic or GMCC DC Inverter Compressor with EVI System
Refrigerant				R32 or R290
Fan Motor				Nidec DC Brushless Motor
Circulation Pump				Wilo or AWANT DC Variable Frequency Circulation Water Pump
3-Way Valve				Honeywell
Controller				Wired Touchscreen Controller with WIFI and Custom Language
Water Heating Exchanger				SUS316 & Cooper Brazed Plate Heat Exchanger
External Cabinet				1.5MM Galvanized Steel With Powder Coating
Electronic Expansion Valve				Dunan or Danfoss
Certificates				CE	ERP A+++	UKCA	ISO 9001	FCC
Outdoor Air Flow			m3/h	2600	5600	5600	7800	7800
Rated Pressure Drop			kPa	30	45	45	40	47
Max Working Pressure		Refrigerant	Bar	44 Bar
		Water	Bar	7 Bar
Water Flow (Built in Pump)			m3/h	1.5	2.4	2.8	4.1	5.2
Expansion Tank			L	2L
Water Pipe			-	DN25	DN25	DN25	DN32	DN32
Noise in 1M			dB(A)	≤50	≤56	≤57	≤59	≤60
Unit size			mm	925*375*770	1050*400*1350		1175*400*1482
Net Weight / Gross Weight			Kg	92 / 106	125 / 150	130 / 155	175 / 202	185 / 212

Key parts of Mango all in one heat pump water heater DC inverter heat pump
Hydrophilic plus-size-area fins, ripple copper pipe...
Applicarion of Mango all in one heat pump water heater DC inverter heat pump

Good comments
Send your inquiry, right away!
For detail of our Mango all in one heat pump water heater DC inverter heat pump

---
