Push Button Switch Lay5-Ba42 Button, Xb4 Button, 22mm Metal Button Flat Button Green Start Button Switch Push Button Switch High Quality Push Button Switch

US$0.20-0.50 400 Pieces (MOQ)

Basic Info.

Model NO.
LAY5-BA42
Wiring
Null Line and Live Line
Principle
Normal
Application
Home Appliance, Electronics, Industrial, Apartment/Villa, Commercial
Type
Normal Close
Number of Switch
Single Control Switch
Structure
Power Built-in Type
Usage
Control Button, Start Button, Limit Button, Reset Button, Check Button, Playback Switch, Disconnector, Change-over Switch, Control Switch
Kind
Single-pole on-off Switch
Contact Type
Type a Contact
Detection Method
Retro-reflective Mode
Brand
Weirro
Certification
ISO9001, CE, SGS/CE
Flat Button
Start/Stop
Conventional Thermal Current
Ith 10A
Rate Value AC
AC-15, 36-380V
Rate Value DC
DC-13, 24-250V
Temperature
-25~+55
Protection Degre
IP40/65
Working Life
3000000 Times
Transport Package
20PCS/Inner Box, 200PCS/CTN
Specification
22mm
Trademark
weirro
Origin
China
HS Code
853650000
Production Capacity
50000PCS Per Month

Product Description

Introducing the Push Button Switch Lay5-Ba42 Button, Xb4 Button, a high-quality, professional-grade switch designed for industrial applications. This 22mm metal button features a flat, green start button, making it easy to identify and operate. With its durable construction and reliable performance, this push button switch is built to withstand the demands of heavy-duty usage. Whether you need to start a machine or activate a specific function, this switch is the perfect choice. Its sleek design and exceptional functionality make it an ideal solution for various B2B applications. Upgrade your equipment with this top-notch push button switch today.pls do not hesitate to contact to us if you have any needed.
Product Desciption:
Test Standard: EN60947-5-1:2017
Ambient temperature: -25ºC~+55ºC
Pollution Grade: Class 3
Protection Grade: IP40/IP60
Ui(V): AC660V
Ith(A): 10A
Voltage of Working: 2.5KV(AC valid value )1M
Insulated resistance: ≤50MΩ
Rated Capacity AC-15: 220V/6A,380V/4A,660V/2A
Rated Capacity DC-13: 24V/6A,48V/3A,110V/1A,220V/0.5A,440/0.25A
Working Life: ≥1000X1000
Class installation: II
Short-circuit Protection: RT16-10A
Cable gland: PG13.5
Vibration Resistance: ≥10g
