| US$3,000.00-3,500.00 | 1 Piece (MOQ) |
| Parameters | Unit | KGS150 | |
| Working Surface of Table | mm | 150×450 (5.9"×17.7") | |
| Max.Table Travel | mm | 480 | |
| Max.Cross Travel | mm | 165 | |
| Distance Between Table Surface and Spindle Center | mm | 360 | |
| Max.Table Load | kgs | 100 | |
| T-Solt(Number×Width) | mm | 1×14 | |
| Table Speed | m/min | Manual | |
| Crossfeed Handwheel | 1gard | mm | 0.01 |
| 1 rev | 2.5 | ||
| Automatic Crossfeed of Saddle | mm | - | |
| Power Cross Feed | 50HZ | mm/min | - |
| 60HZ | - | ||
| Grinding Wheel Dimensions | mm | 180×13×32/31.75 | |
| Spindle Speed | 50HZ | rpm | 2850 |
| 60HZ | 3420 | ||
| Vertical Handwheel | 1gard | mm | 0.005 |
| 1 rev | 1.25 | ||
| Automatic Down Feed Rate | mm | - | |
| Power Head Increment | mm/min | - | |
| Spindle Motor | kw | 1.1 | |
| Vertical Motor | w | - | |
| Hydraulic Motor | kw | - | |
| Dust Collection Motor | w | 550 | |
| Coolant Motor | w | 90 | |
| Crossfeed Motor | w | - | |
| Floor Space | mm | 1900×1300 | |
| Packing Dimensions | mm | 1100×1020×1950 | |
| Net Weight | kgs | 620 | |
| Gross Weight | kgs | 710 | |
| 1 | Grinding wheel | 2 | Wheel flange |
| 3 | Wheel balancing base | 4 | Wheel balancing arbor |
| 5 | Extractor | 6 | Diamond dresser |
| 7 | Leveling pad | 8 | Anchor bolt |
| 9 | Tool box with tools | 10 | Permanent magnetic chuck |
| 11 | Cooling system | 12 | Work light |
