Steam Heating Home Made Distillation Kit Frankincense Bamboo Rose Lemon Lavender Essential Oil Distiller Extraction Machine

Product Description

Usage Scope:Basket Type pressure steam Essential Oil Distill Extraction Tank uses the steam direct distillation method or use the jacket indirectly heating to distill the essential oil .1. put the fresh or dried aromatic raw materials like the Vetiver, lemongrass, Aquilaria, eucalyptus, thyme. Rosemary, lemon balm, primrose etc into the extraction distiller tank2. heating the extraction distill tank by steam or electrical etc .3.heating till inside shell the raw material boiling and vapor 4.condensate the vapor gas by condenser 5.collection the condensated extraction solution 6.collect the essential oil For the steam distill type Basket Type pressure steam Essential Oil Distill Extraction Tank composition : Basket Type pressure steam Essential Oil Distill Extraction Tank including the following unit : extraction tank ,stainless steel feeding basket ,condenser ,sub-cooler ,oil- water separator unit and pipeline .essential oil distillation extraction machine use the steam directly distill from the extractor tank bottom ,the aroma oil will vapor outside with the steam together ,then cooling by the cooling water and chiller in the condenser and sub-cooler ,the oil with water will enter into the oil/water separator ,the oil and water will separate into two layers due to the different gravity . the aroma essential oil can be collected in the storage tank ,the water can be drain outside .Basket Type pressure steam Essential Oil Distill Extraction Tank structural features:1. The internal and external precision polishing of the equipment meets GMP requirements.2. The equipment is mainly composed of distillation tank, basket, condenser, cooler, oil-water separator, etc.3. The cover of distillation tank is quick opening, which is convenient for disassembly and lifting out the internal hangingbasket. The heating mode is through steam heating.4. The equipment uses the characteristics of volatile oil and solvent with different boiling points, which are volatile, toseparate them from the solvent and collect them.5. This equipment provides a new method for the production of special aroma essential oil extraction machine .6. distill extraction machine capacity from 20L to 10000L .7.material can be made SS304 or SS316L .

model	TQC-500	TTQC-1000	TQC-3000
Distiller tank volume (L)	500	1000	3000
Raw material feeding (KG)	50-150	200-300	600-800
condenser cooling area( M2)	5	8	15
Sub-condenser cooling area (M2)	1.5	2.5	5
steam inlet pressure (Bar)	2-3
oil /water separator material	glass/SS304
collection tank	30L	50L	100L

SERVICE
We have established some overseas agent office to make the after-sales serivce already ,so it can will be service client in fast response .also in our headquarter service team ,there is a expert team which can support client in 7*24 hours .
1. Customer inquiry and consultation (URS documents)
2. Confirmation of treatment plan (DQ documents &PID Drawing)
3.Quotation offer with the technolgy document (Quotation PI )
4.Engineering and Manufacturing (Prodcution &Quality inspection )
5. Product inspection (FAT documents)
6. Delivery arrangement and loading work (full set Shipment documents)
7. After-sales service (OQ,PQ ,SAT documents)
FAQ
1.What about your factory?
Our factory is located in Wenzhou city ,Zhejiang Province and have more than 15 years experience on machinery making.
2.How will your company control the equipment quality ?
We have a qualified expert team ,we will inspect every production proceed .also Machines will be tested in our plant before shipment .
3.How long the warranty will be?
We provide 1 years warranty for the machine running ,but we will afford whole -life service for the machine .
4.Which kind payment do your company do now ?
We accept Western Union, T/T ,D/P,D/C and irrevocable L/C payable etc.
5.Can we become your distributor in our country?
Yes, we very welcome you! More details will be discussed if you are interested in being our agent.
6.Why we choose "JOSTON "?
1. We enhance the reliability of product's quality and working life .
2. We decrease the consumption cost of the product in the ruuning.
3. We improve research personnel's ability to deliver a creative design;
4. We use leading technologies in our product development and innovation, and thereby increase the competitive advantage of products.
7.Do you supply installation equipment in oversea?
Yes, if need, we can send our engineer to your plant to help you do installation and commission.
8.How can we know the order production status ?
We will arrange the person to take photo or video during manufacturing in every week to make you to know the production status.When goods are finished,we will take detailed photos or video for your checking ,after approve ,then we will arrange shipment .also you can arrange FAT in our plant when the goods is ready here
9.what is kind service do you offer before making order ?
1.according to your company URS ,we will make the design drawing accoridingly.
2.after your company approved drawing ,we will make quotation.
3. final we make agreement on payment terms ,delivery time ,package ,shipment etc.
10.how about your company after-sale serivce ?
1. We provide long-term after-sale service.
2. we can do installation and commission for the equipment in your plant if necessary .
3. Meanwhile, you can call or e-mail us to consult on any relevant question since we have a special line for after-sale service. Alternatively, you can communicate on-line with us to solve any problem.

---
