Slant Bed CNC Lathe Machine Center

Product Description

CLK520 SLANT BED CNC LATHE MACHINE
1. CLK520 SLANT BED CNC LATHE MACHINE SPECIFICATION

max. swing over bed	mm	520
max. swing voer cross slide	mm	320
max. processing length	mm	500/1000
X/Z axis travel	mm	220*500/1150
spindle nose		A2-8
spindle bore	mm	80/130
spindle drawing pipe diameter	mm	60
max. spindle speed	rpm	2500
chuck size	inch	10
spindle motor power	kw	7.5
X/Z position accuracy	mm	0.016/0.02
X/Z repeatability	mm	0.006/0.006
X/Z feed motor torque	N.m	5/7.5
X/Z feed motor power	kw	1.3/1.88
X/Z feeding speed	m/min	10
tailstock travel	mm	350
tailstock sleeve diameter	mm	100
tailstock taper		MT5#
tool post type		8 station hydraulic turret
cutting tool shape size	mm	25*25
guide type		Taiwan HIWIN linear guide way
total power capacity	kvw	15
machine dimension L*W*H	mm	2450*1600*1700
N.W.	kg	4200

2.CLK520 SLANT BED CNC LATHE FEATURES
Taiwan high accuracy HIWIN linear
Taiwan famous brand ball screw
hydraulic magazine
hydraulic chuck
hydraulic tailstock
thur-hole type rotary cylinder
3. CLK520 SLANT BED CNC LATHE USAGE
This machine is applicable to automobile, motorcycle, electronics, aerospace,oil and other
industry. It could turn the conical surface, circular arc surface, end face of the rotary parts, could also
turn various metric and inch threads etc, with higher efficiency and higher precision in bulk.
4.CLK520 SLANT BED CNC LATHE STANDARD ACCESSORIES
GSK980TDC or Siemens 808D
Servo main motor 7.5kw
8 station hydraulic magazine
10" domestic thru-hole type hydraulic chuck
hydraulic tailstock
lubrication system
coolant system
lighten system
5.CLK520 SLANT BED CNC LATHE OPTIONAL ACCESSORIES
NC System: Mitsubishi E60, Fanuc Oi Mate-T
Main Motor: Servo11/15KW
Inverter15KW
Chuck: 10″Non-through hole hydraulic chuck
10″Non-through hole hydraulic chuck (Taiwan)
10″through hole hydraulic chuck(Taiwan)
12″Non-through hole hydraulic chuck (Taiwan)
12″through hole hydraulic chuck(Taiwan)
Chip conveyor
Steady Rest
Without hydraulic tailstock

---
