LPCB Standard 2x1.0mm2 2 Core PH30 PH120 Shielded LSZH Fire Resistant Cable

Product Description

PH30 PH120 Fire Resistant Fire Alarm Cable Product Description
Fire Resistant Cables are suitable for high buildings, entertainment venues and many high-quality and high demand security construction projects. They are used in fire protection systems for fire elevators, fire pumps, fire alarms,smoke exhaust systems, emergency lighting, fire hazard areas, high temperature applications and special requirements on power supply lines for safe facilites etc.

Conductor	Stranded Bare copper, class 1
Insulation	200°C silicone
Binding tape	compound mica
Drain wire	≥0.5mm tinned copper
Shielding	fire foil
Sheath	90°C LSZH polyolefin
Physical mechanical propert	insulation tensile strength ≥5.0 MPa elongation at break ≥200%, sheath tensile strength ≥10.0MPa, elongation at break ≥100%
Min bend radius	10 x D, at -15°C Min bend dia ≤12.5mm
Operating voltage	300/500v
Testing voltage	2000v
Operating temperature	-20°C + 90°C
Fire test alone	950°C, 180 mins
Fire test with water	650°C 15mins,then apply fire and water together 15mins
Fire test with impact	950°C, 15min/30times

Our Advantages * Low smoke, no halogen, fire retardant, fire resistant, environmental
* Low smoke in fire, no halogen which decrease the damage to equipments and humans * High retardance to fire, self- extinguishing * Long operational life span, equal to structures life span * Higher resistance to electromagnetic interferencen * Superior earth continity (The bare CPC is placed between two metallic tapes) * Enhanced resistance to cable kinks (Subsequently protecting cables performance) * Extremely robuast/durable design (Due to increased tape numbers and overlap) * Improved data transmission (Due to twisted cores and additional screening)

Part	Item Structure	Conducor	Insulation	Diameter	Sheath	Overall Diameter(mm) min	Overall Diameter(mm) max	Resistance of conductor at 20ºC:Ω/KM
ET 210	2c1.0+E	30/0.2mm	Silicone	2.2	LSZH	7.2	8.2	18.1
ET 310	3c1.0+E	30/0.2mm	Silicone	2.2	LSZH	8.5	9.5	18.1
ET 410	4c1.0+E	30/0.2mm	Silicone	2.2	LSZH	9.5	10.5	18.1
ET 215	2c1.5+E	30/0.24mm	Silicone	2.55	LSZH	7.2	8.2	12.1
ET 315	3c1.5+E	30/0.24mm	Silicone	2.55	LSZH	8.5	9.5	12.1
ET 415	4c1.5+E	30/0.24mm	Silicone	2.55	LSZH	10.5	11.5	12.1
ET 225	2c2.5+E	50/0.24mm	Silicone	3.2	LSZH	8	9	7.41
ET 325	2c3.5+E	50/0.24mm	Silicone	3.2	LSZH	9.5	10.5	7.41
ET 425	2c4.5+E	50/0.24mm	Silicone	3.2	LSZH	11.5	12.5	7.41
... ...	... ...	... ...	... ...	... ...	... ...	... ...	... ...	... ...

FAQ:
Q1: What kind of cable do you produce?
A: We specialized in producing Fire alarm cables, Alarm/security cables, Speaker cables, Coaxial cables, Data cables, HDMI cables, telecommunication cables, telephone cables, power cables and other various of cables and wires
We also provide cable accessory products such as connector, cable clip,cable tie,crimping tool, antenna dishe,splitters,amplifer,optical receiver,optical transmitter etc
Q2: What's your MOQ? Can you offer free samples?
A: Our MOQ is 10KM per item. Free samples can be sent to you if available in stock,freight cost need to be paid by your side.
Q3: What's your delivery time?
A: Normally, our delivery time is 15 days after received deposit,it base on the quantity of the order.
Q4: What's your payment term?
A: We accept T/T, L/C,Western Union.Other payments accept through negotiation.
Q5:What's your trade term?
A: We accept FOB ShangHai or Ningbo,CFR,CIF,EXW term
Q6: Where is your factory located? How can I visit there?
A:Our factory is located in Ningbo City, Zhejiang Province, China, about 30 minutes away from Ningbo Lishe Airport .All our clients, from home or abroad, are warmly welcome to visit us!

---
