| US$2,100.00 | 1 Piece (MOQ) |
Description | CQ6232Ex880 / CQ6232Ex1000 |
| Max. swing over bed | 320 mm |
| Max. swing over gap | 470 mm |
| Max.turning dia.over cross slide | 198 mm |
| Max.length to be turned | 880 mm / 1000 mm |
| Speed steps | 8 |
| Speed range | 70~2000 RPM |
| Spindle bore dia | 38 mm |
| Taper of spindle bore | MT No.5 |
| Longitudinal | 0.079~1.291 |
| Transverse | 0.017~0.276 |
| Metric threads | 0.4~7 |
| Whitworth threads | 4~60 |
| Cross slide travel | 160 mm |
| Top slide travel | 76 mm |
| Swiveling angle of turret | ± 45 ° |
| Distance from the tool bearing surface to centerline | 18 mm |
| Movement of tailstock quill | 100 mm |
| Taper of tailstock quill bore | MT No.3 |
| Power of main drive motor | 1.1 or 1.5KW |
| Packing size (1 package) <LxWxH> | 168x75x140cm / 185x75x140cm |
| Gross weight (kg) | 560 / 600 |
| Packing size (3 packages) <LxWxH> | 168x74x75cm / 185x74x75cm 69x40x37cm 69x40x30cm |
| Gross weight (kg) | 490/ 30/ 27/530/30/ 27 |
