Product Description
Product Description
Product DescriptionMain Features:DK7755 wire cutting machine body is the use of high-strength cast iron (HT250) forming the base for the machine load-bearing parts. Integral structure, DK7755 wire cutting machine casting body are used resin casting technology casting (walking wire on the use of this technology), two high-temperature annealing, DK7755 line cutting machine in the same type of machine weight is also large, to ensure that mechanical precision The constant change.SpecificationDK7755Working table travel550mm*850mmCutting the maximum thickness of the workpiece600mm AdjustableWorking table size750mm*10500mmCutting the workpiece the maximum taper 30°Maximum cutting efficiency100mm2/min (Cr12 40mm thickness)Maximum cutting current5ARoughnessRa≤2.5μm (Cr12 40mm thickness)Precision0.015 (Φ10mm)Machine power consumption3kwElectrode wire diameterΦ0.18mmTake the wire speed11m/sDrive modeStepperControl methodOpen-loop controlMachine Dimension1865mm*1720mm*1700mmWeight of machine bed2450kgCompany ProfileFAQQ1: How is the warranty? A1: Warranty time is 13 months after BL date. Q2:Can we visit your factory before order? A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking. Q3:Do you have a stock? A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs. Q4:What’s the MOQ? A4:One set only. Q5:How about your quality? A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services. Q6:Do you have professional engineers? A6:Yes.we have professional engineers and designers. We can provide OEM services. Q7:Can you provide customized machines? A7:Yes, we can design and manufacture according to your specific requirements.
