| Model | BME-500D | BME-500E | BME-500SM | BME-500V |
| Viewing head | Monocular Head Inclined at 45°,360° rotatable | Compensation Free Binocular Head Inclined at 30°,360° rotatable | Compensation Free Trinocular Head,360° rotatable | Dual viewing head, one tube 30°,inclined and another tube vertical, 360° rotatable |
| Achromatic Objectives | 4X,10X,40X(S),100X(S,Oil) |
| Eyepiece | Wide Field Eyepiece :WF10X,(WF16X optional) |
| Stage | Double Layer Mechanical Stage Size 120*125mm |
| Focusing | Coaxial Coarse and Fine Adjustment, Focusing Range 30mm, Focusing Interval 0.002mm |
| Condenser | Abbe NA=1.25 with lris Diaphragm&Filter |
| IIIumination | LED(1W) Lamp 220V or 110V ( LED 3W lamp optional) |
| Power Supply | AC110/220V±10%, 50/60Hz |
| Package Size | 370*230*470mm |
| Gross Weight | 5kg |
