| Model | GS1000 | GS2000 | GS3000 | GS4000 | GS5000 | GS6000 | |
| AC Input | Nominal Power | 1000W | 2000W | 3000W | 4000W | 5000W | 6000W |
| Voltage | 120VAC/230VAC | 230VAC | |||||
| Acceptable Voltage | 194-243VAC/164-243VAC(wide mode) | ||||||
| Line low Transfer | 85V±4%/184(154 wide mode±4% ) | ||||||
| Line low Return | 95V±4%/194(164 wide mode±4% ) | ||||||
| Line high Transfer | 135V±4%/253±4% | ||||||
| Line high Return | 127V±4%/243±4% | ||||||
| Frequency | 50Hz or 60Hz (auto sensing) | ||||||
| Line low Transfer | 47Hz for 50Hz, 57Hz for 60 Hz | ||||||
| Line high Transfer | 55Hz for 50Hz, 65Hz for 60 Hz | ||||||
| Out Input | Phase &waveform | Pure Sine Wave(bypass mode sync to input) | |||||
| Voltage | 100/110/120/130VAC, 208/220/230/240VAC (bypass mode sync to input) | ||||||
| Voltage Regulation | ±10%rms(bypass mode sync to input) | ||||||
| Frequency | 50Hz±0.3Hz(bypass mode sync to input) | ||||||
| Peak Power | 3 times of rating power | ||||||
| Short Circuit Protection | Yes, shutdown after 10ms | ||||||
| Power Factor | 0.9-1.0 | ||||||
| DC Input | Battery Voltage | 12V/24V/48V | 24V/48V | ||||
| Minimum Start Voltage | 10V for 12V, 20V for 24V, 40V for 48V | ||||||
| Low Battery Alarm | 10.5V for 12V, 21V for 24V, 42V for 48V | ||||||
| Low Battery Transfer | 10V for 12V, 20V for 24V, 40V for 48V | ||||||
| High Voltage Alarm | 16V for 12V, 32V for 24V,64V for 48V | ||||||
| Max Charging Current | 20A/35A/70A/90A | ||||||
| Over charge Voltage | 15.7V for 12V,31.4V for 24V, 62.8V for 48V | ||||||
| Transfer Efficiency | Line Mode | >95% | |||||
| Battery Mode | >88% | ||||||
| Power saver | Available when the load is less than 25 Watts | ||||||
| Indicators | Switch selector | Saving Mode is on/off when push the switch forwards/backwards , Keeping it horizontal is turning the inverter off. | |||||
| Audible Alarm | Sounding when the heatsink's tem is over 105ºC and shutdown after 30 seconds. | ||||||
| Protections | low battery/ over charging /over temp/over load | ||||||
| Communications | RS-232/USB(custom-made) | ||||||
| Enviromental | Operating Environment | 0-40ºC,0-90%ºC RH(non-condensing) | |||||
| Audible Noise | <60dB | ||||||
| Net Weight (KG) | 18 | 20 | 22 | 35 | 38 | 40 | |
| Dimension (LxWxH) | 446×218×179mm | 605×218×179mm | |||||
