US$28,000.00-31,000.00
|
1 Set
(MOQ)
|
Basic Info.
Usage
Ceramics, Granite, Marble
Application
Machinery & Hardware, Art & Craft, Stone Industry
Cutting Ability
High Speed
Stone Can Cut
Marble and Granite
Main Motor Power
55(4p)Kw
Mx. Blade Diameter
φ2500mm
Slab′s Thickness Can Cut
17/20/30mm,etc.
X Axis Maximum Stroke
13m/MIM
Transport Package
Plastic Film Packing
Specification
7800x5000x4500mm
Origin
Putian, Fujian, China
Production Capacity
50PCS/Month
Packaging & Delivery
Package Size
780.00cm * 500.00cm * 450.00cm
Package Gross Weight
14000.000kg
Product Description
Multi blade Stone Cuitting Machine HLQY-3000 is a classic and practical bridge saws for cutting block into slabs, thin or thick. which adopts Siemense PLC control system, Hiwin linear guide with oil bath. Up to 18 pieces of thin saw blades can be mounted.
It's popular in China and abroard for its high efficiency, good stability and long life service.
TECHNICAL DATA
|
Model
| HLQY-1600
| HLQY-2500
| HLQY-3000
|
Max. blade diameter
| mm
| Φ1600
| Φ2500
| Φ3000
|
Cross beam type
|
|
| A / B
| A / B
|
Cross beam length
| mm
| 6000
| 7600 / 8300
| 8300 / 9300
|
Cutting length
| mm
| 3500
| 3500
| 3500
|
Cutting wideth
| mm
| 2000
| 2000
| 2000
|
Lifting stroke
| mm
| 800
| 1350
| 1350
|
Power of main motor
| kw
| 55 (4P)
| 55 (4P)
| 55 (6P)
|
Power of pump motor
| kw
| 4
| 4
| 4
|
Power of stroke motor
| kw
| 2.2
| 2.2
| 2.2
|
Power of vertical motor
| kw
| 1.1
| 1.1
| 1.1
|
Gross power
| kw
| 62.3
| 62.3
| 62.3
|
Gross weight
| kg
| 10000
| 13000/14000
| 14000/15500
|
Dimensiona(L x W x H)
| cm
| 650x500x400
| 780x500x450
| 780x500x450
|
Main Features 1) Siemens smart PLC control system makeshigh automation performance and easy.
2) Adopts 4 pillars for spindle sliding, which ensure the structure of the machine is steady and the lifting is stable.
3) Two-slider frame structure driven synchronized by screw with high stiffness and stability.
4) Sliding system of X and Y axes on linear guides and racks both in oil bath lubrication grants smooth and high production.
Q: Are you manufacturer ?
A: Yes, we are professional and top stone machine manufacturer more than 30 years in China. Also we have many authorized agents all over the world to take care of machine's after sell service.
Q: Can I get a machine according to my own requirements?
A: Sure. Welcome OEM and ODM orders.
Q: This is the first time I use this kind of machine, is it easy operate?
A: There are guide video that show how to use machine and English instruction manual sent to you with machine. If there is still have any question, we will provide free professional online guide for you until you could use machine well.
Q: What's your MOQ and delivery?
A: Our MOQ is 1 set. We could send machine to your country port or to door directly, please tell us your port name or address. We'll offer the most competitive price and freight to you.
Q: How is your after sales service?
A: We offer machine lifelong's free online guide service. And many countries we have local dealer to do machine's installation and maintenance.
Q: If my machine is broken. Can you repair it for me?
A: Yes, many machines of us have remote troubleshooting function, we can solve by remote control and video guide. Re. common problems, we have professional guideline to show how to replace the parts, and for the countries which our agents cover, they will repair for you as well.
>>
