Product Details
Product Description
Product Description
Specifications
Cloth banner printing machine
1.120-160m/h print speed
2.Save 40-50% ribbon
3.Can do offline work
4.Save manual power
Advertising Machinery Cloth Banner Printing Machine
Specification of cloth banner printing machine
1. With holding shaft, the using life can be lengthen 2-3times.
2. Double tension adjusting: with tension adjustment of stepping shaft and ribbon shaft, the user can adjust the tension anytime to get rid of wrinkle between cloth and ribbon.
3. Static brush: The machine can eliminate static electricity with static brush, and to protect the print head.
4. Strength support of square pipe: can make sure that the machine work for long time stably.
5. Printing method: network interface, USB, SD card, off-line work
6. High speed printing: 80-220m/h
7. Multifunctional control panel: five silicon control which can make printing effect obviously.
8. Swivel Castor: only need one person to operate the machine, which can save manual power.
Details of cloth banner printing machine
Technical parameter of cloth banner printing machine
Model
| AZSTFJ1000A
| AZSTFJ1000B
| AZSTFJ1200
| AZSTFJ1500
|
Dimension
| 1600x600x1000mm
| 1620x700x1160mm
| 1860x700x1160mm
| 2160x740x780mm
|
Banner width
| 1000mm
| 1000mm
| 1200mm
| 1500mm
|
Actual print width
| 768mm
| 768mm
| 768mm
| 1024mm
|
Voltage
| AC220V/50HZ/60HZ
| AC220V/50HZ/60HZ
| AC220V/50HZ/60HZ
| AC220V/50HZ/60HZ
|
Power
| 500-800W
| 500-800W
| 600-1000W
| 1000-1500W
|
Print speed
| 80-160m/h
| 120-220m/h
| 120-160m/h
| 80-160m/h
|
Repeat precision
| 5mm
| 5mm
| 5mm
| 5mm
|
Print media
| Thin film, card paper, ordinary cloth
| Thin film, card paper, ordinary cloth
| Thin film, card paper, ordinary cloth
| Thin film, card paper, ordinary cloth
|
Print interface
| USB off-line print, wireless print
| USB off-line print, wireless print
| USB off-line print, wireless print
| USB off-line print, wireless print
|
Weight
| 80kg
| 90kg
| 100kg
| 280kg
|
Product of different cloth banner printing machine
Application of cloth banner printing machine
