1050 1060 1100 3003 Psmb Aluminum Coil/Aluminium Coil with Polysurlyn Film /Aluminum Coil Roll /Polysurlyn Moisture Barrier Aluminum Coil Roll

Product Description

Product Description
Polysurlyn Moisture Barrier Aluminum coil is a protective film formed by hot pressing polysurlun film onto the surface of aluminum coil through hot pressing. This film is closely adhered to the surface of aluminum coil and is not easy to fall off. Polysurlyn film is a polyethylene and sarin polymer multilayer composite film with a total thickness of 76 microns.
Polysurlyn moisture barrier aluminum coil can effectively help the metal protection layer of pipeline insulation materials in oil refineries (power plants and chemical plants) to prevent corrosion, because it has good metal adhesion, good air tightness and excellent anti-corrosion performance, and is an ideal material for pipeline anti-corrosion protection layer.
1. We confirm there is no more than 5 pinhole detections, collectively are detected in the 10 wetted test areas in accordance with ASTM C1729 - Pass criteria for moisture retarder.
2. We confirm that water vapor transmission rate of the moisture retarder will be less than 1.55g/m2/day.

Product Parameters
PSMB (Polysurlyn Moisture Barrier) Aluminum Coil Jacketing Polysurlyn coatedIntroduction to Polysurlyn Film :1. The Polysurlyn film has three layers in total.First layer: PE filmMiddle layer: Zn++ Ionomer SurlynThird layer: EAA2. Thickness: 0.076mm3. Weight: 80g per square meter4. JINAN ZHAOYANG ALUMINIUM INDUSTRY CO promises to you as follows:1) We confirm there is no more than 5 pinhole detections, collectively are detected in the 10 wetted test areas in accordance with ASTM C1729 - Pass criteria for moisture retarder.2) We confirm that water vapor transmission rate of the moisture retarder will be less than 1.55g/m2/day.What kind of Aluminum Sheet Coil can be covered with POLYSURLYN FILM?1. Aluminum series: 1050, 1060, 1100, 3003, 3004, 3105, 5005, 5052, 5754, 8011, etc.2. Aluminum Thickness: 0.2mm ~ 1.5mm3. Stainless Steel: SS304, SS3164. Stainless Steel Thickness: 0.2mm ~ 1.2mmCLASSIFICATION:1. Aluminum Coil/Stainless Steel Coil with Polysurlyn Film one side only.2. Aluminum Coil/Stainless Steel Coil with Polysurlyn Film one side, and Blue Film Protector on another one side.3. Aluminum Coil/Stainless Steel Coil with Polysurlyn one side, and PE or PVDF color coating on another one side.4. Aluminum Coil/Stainless Steel Coil with Polysurlyn one side, and Polysurlyn film on another one side.5. Aluminum Coil/Stainless Steel Coil with Polysurlyn one side, and Kraft Paper on another one side also.What are the forms of Aluminum/Stainless Steel Sheet Coil covered with Polysurlyn film?1. Aluminum/Stainless Steel Roll with Polysurlyn film50meters, 150meters, 100kgs, 200kgs, 250kgs, 300kgs or 500kgs per CoilCoil ID: 176mm, 200mm, 300mm, 505mm2. Aluminum/Stainless Steel Coil with Polysurlyn film1000kgs, 1500kgs, 2000kgs, 2500kgs, 3000kgs per CoilCoil ID: 505mm3. Aluminum/Stainless Steel Sheet with Polysurlyn film1000kgs, 2000kgs per Non-fumigation pallet4. Corrugated Aluminum Sheet with Polysurlyn filmWhat is the function of Aluminum/Stainless Steel Sheet Coil covered with Polysurlyn film?Aluminum/Stainless steel Sheet Coil is specially used in the pipeline insulation industry. Its purpose is the same as aluminum Coil with kraft paper, but the Polysurlyn film has better quality than kraft paper. Aluminum/Stainless steel Sheet Coil is widely used in the thermal insulation, anti-corrosion and moisture-proof of power plant desulfurization, flue insulation, oil field petrochemical, chemical plant, nuclear power plant and other pipelines.MOQ of Aluminum/Stainless Steel Sheet Coil with Polysurlyn film is 3000kgs.Packing: Non-fumigation PalletProduction time: 30 days if the quantity is less than 200 tons.
Product features
Polysurlyn Moisture Barrier Aluminum coil can be effectively applied to the anti-corrosion engineering of the pipeline insulation material aluminum coil plate protection layer in the oil refinery, power plant, chemical plant and other high requirements of anti-corrosion construction environment. Polysurlyn film on aluminum coil has excellent adhesion, excellent air tightness and corrosion resistance. The polysurlyn film has low flammability after being applied to the aluminum coil, which has more advantages of waterproof and increased weather resistance. Become an ideal emerging material for pipeline anti-corrosion protection layer.

Isulation material	Polysurlyn moisture barrier
Surface	Stucco embossed or smooth
Alloy	1050, 1060, 1100, 3003, etc
Temper	H14/H24
Width	200-1500m
Thickness	0.3-1.5mm
Barrier color	Blue
Barrier thickness	3 mils (76um)
Protection	Plastic film covered
Delivery	Within 25 days
Package	Standard seaworthy exporting packing
MOQ	3 tons

Detailed Photos
Packaging & Shipping

Certifications
Our Advantages
QUALITY
JINAN ZHAOYANG ALUMINIUM INDUSTRY CO., LTD. has the advanced testing equipments and builds up a professional scientific research team,strictly control the quality on each steps of production. including inspection on raw materials entry, product's color analysis during production,T-bend test, impact test, salt-spray test, tensile test and packaging testing on exported products , which ensures its integrated performance such as corrosion resistance, coating stickiness etc. and the safety of transportation.
SERVICE
Nowdays, economic globalization promotes international trade, and our products are sold to many countries and regions in the world.
This makes our products very popular not only in the domestic market, but also in Europe, the United States, Mexico, Colombia, Chile, New Zealand, Dubai, Pakistan, Singapore, Thailand, the Philippines, Vietnam and other countries and regions, winning the trust and praise of customers and successfully moving from home to abroad.
FAQ
Q1. Where is your factory ?
A1: Our factory is located in Yushan Technology Incubation Park,Pingyin County, Jinan City, Shandong, China
Which is well equipped with kinds of machines, such as Aluminum plate machine, Aluminum circle machine, Embossed aluminum coil machine, aluminum roofing sheet machine,kraft paper/Polysurlyn/pvc film coated aluminum coil machine, aluminum foil machine, and so on.
We can provide a wide range of personalized services according to the customers' needs.Q2. What are your company's main products ?
A2: Our main products are Aluminum plate/sheet, aluminum coil, aluminum circle/disc , aluminum foil, aluminum roofing sheet, aluminum roll with kraft paper/polysurlun/blue pvc film, embossed aluminum sheet/plate, color coated aluminum coil/sheet, aluminum pipe, aluminum wire, etc.Q3. How do you control quality ?
A3: Mill Test Certification is supplied with shipment, Third Party Inspection is available.Q4. What are the advantages of your company ?
A4: We have our own production workshop, logistics and transportation team, many professional and technical personnel, more competitive prices and the best after-sales service than other aluminum product companies.Q5. How many coutries you already exported ?
A5: Exported to more than 50 countries mainly from America, Canada, UK, Spain, Colombia, Chile, Brazil, Peru, Argentina, Vietnam, Singapore, Malaysia, Thailand, Pakistan, Bangladesh, India, New Zealand, Nigeria, Ethiopia, Kuwait, Jordan, etc.Q6. Can you provide sample ?
A6: Yes, small samples are free, and the freight collect.
Customized samples will take about 5-7days.

---
