3 Axle Low Bed Truck Trailer Parts 50 60 Ton Lowboy Trailer Ramps

Product Description

3 axle low bed truck trailer parts 50 60 ton lowboy trailer ramps
Product Description LowBed Semi Trailer as known as low bed trailer, lowbed trailer, lowboy trailer,can make 3axles, 4 axles, 5 axles, 6 axles. There are generally used to transport construction machinery and large equipment.we can design it according to your requirement.
Detailed Photos
Product Parameters

Specifications for 3 axle low bed truck trailer parts 50 60 ton lowboy trailer ramps
Type	Lowbed semi trailer
Overall Dimension	13000x3000x1650mm
Dimension	9000*2500*1300
Tare weight	Approx. 8000kgs-12800kgs
Capacity	30 ton - 100 ton
Main beam	Height 450mm-520mm, upper plate is 14mm-25mm, middle plate is 14mm-25mm, down plate is 16mm-25mm, material is Q345B steel
Side beam	16 mm- 25 mm channel steel (Material is Q235 steel)
Platform	3 mm - 5 mm thickness chequered plate or can be optional
Gooseneck	For chosse
Ladder	Manual type or Hydraulic type
Axle	13/16T, FUWA / BPW / SHENGRUN brand etc
King pin	Jost 2.0 or 3.5 inch bolted type
Suspension	Mechanical suspension / Germany type or America type / Air suspension
Leaf spring	90 mm(Width) * 13 mm(Thickness) * 10 layer or 100 mm * 12 mm * 12 layer
Braking system	WABCO 6 relay valve, spring brake chamber, 2 pieces of 45L air tank
Rim	9.0*22.5 / 8.0-20 / 8.5-20
Tire	12.00R22.5 ; 315/80R22.5; 11.00R20; 12.00R20 brand can be optional
ABS	Optional
Fire extinguiser	Two pieces 4 kgs
Spare tire carrier	2 pieces
Safety guard	With standard
Painting	Complete chassis sand blasting to clean rust, 1 coat of anticorrosive primer, 2 coats of finla painting, Color advised by customer.
Accessories	One standard tool box
Light	LED light
Shipping terms	By bulk vessel or RORO or 40 HQ container

Related products
Main products
1. Dump Truck / Tipper Truck
2. Howo tractor Truck/ prime mover truck
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck
9. Cement Powder Tank truck/ Bulk cement trailer
10. High-altitude operation truck
11.Semi Trailer ( flat bed trailer / skeleton trailer / dump trailer / side wall trailer / low bed trailer / container trailer, etc. )
Packaging & Shipping Shipping method for 3 axle low bed truck trailer parts 50 60 ton lowboy trailer ramps :
Usually Our lowbed trailer can be shipped by Ro-ro ship or Bulk ship or Container or Flat rack.
Packing Detail: Ro-Ro or Bulk base on the ship and port in your country. If the truck on the deck,we will spray antirust paint with free.
Company Profile
FAQ 1. Q: What's your MOQ?
A: One unit trailer or truck.
2. Q: What is your lead time?
A: Usually it is 15-20 days after deposit received.
3. Q: What is the warranty of the trucks?
A: 12 months about engine, axle and transimission, some spare part can be 18 months. And we can help you solve
every problem about the truck by email and phone whole life.
4. Q: What's your payment terms?
A: T/T: 30% deposit by T/T,70% balance should be paid before shipment.
L/C: 100% irrevocable Credit of Letter.
5. Q:If Our Vehicle/Trailer Can Couple With Your Tractor Head ?
A:You can tell me that you are using the Tractor/Primer Mover model or the distance between fifth wheel and the ground,
we can design a height that matches your Tractor.
6. Q:If We Can Provide Terms For Reducing Your Import Duties ?
A:Yes, Please Contact With Us, We Are Nationalized Manufacture With Tax Reduction, Will Also Offer You The Best Way
For Import Duty Reduction.
7. Q: How about the after sales service?
A: We provide technical support and spare parts for long life time of our products.

---
