High-Speed Extrusion Blow Molding Machine (EB25H)

Product Description

Product Description
EB70U High-speed Double Station Extrusion Blow Molding Machine
Powerjet Single Station Extrusion Blow Molding Machine EB70U is specialized for manufacturing bottles and containers with Max 7L.Max Bottle Capacity - 7(L)Clamping Force - 85/110(KN)Extrusion Weight(HDPE) - 80~120(kg/hr)Applications - Wide Range Of Bottles For Daily necessities, toiletries, beverages, water tanks, laundry detergent/shower gel/motoroil bottles, etc
Detailed Photos
FEATURES:
1:Toggle balance clamping structure, with platen opening & clamping and mold platen movement by linear guide, to achieve low friction and high speed.
2 Based on the Finite Element Analysis design, and platen, toggle, and platen frame are made in high-intensity nodular cast iron.
3:High-speed mold clamping oil cylinder with differential speed function, and high-speed mold moving cylinder with special anti-shock cushion valve structure.
4:Specially designed to screw with a high L/D ratio ensures good plasticizing and stable extrusion; high precision and no part line die head guarantees customers' top quality requirement.
5:Multi-screw & multi-die heads can be adopted to improve the quality of the product and lower the cost of material.
6:Multiple-way PID-controlled temperature heating is precise and stable.
Product Parameters

MODEL	UNIT	EB25H55S	EB25H65S	EB25H65-40D	EB25H70S
Max.Product	L	2.5
Clamping Force	kN	53/63
Max. Mold Size(W x H)	mm	380x340
Screw Diameter	mm	Φ55	Φ65	Φ65+Φ40	Φ70
Screw L/D Ratio	L/D	25	25	25+25	25
Screw Rotary Speed	RPM	75	65	65+50	65
Extrusion Weight(HDPE)	kg	35	55	55+11	65
Extrusion Motor Power	kW	11	15	15+4	18.5
Pump Motor Power	kW	7.5
Heating Capacity	kW	14	17	17+4.5	17
Operation Pressure	Mpa	0.6~0.8	0.6~0.8	0.6~0.8	0.6~0.8
Air Consumption	m³/min	1.5
Cooling Water Consumption(25ºC)	L/min	50
Machine Dimension (LxWxH)	mm	3460x2250x2300
Machine Weight	kg	3500	3900	4500	4500
