Reliable Used Rice Harvester with 109HP for Efficient Crop Harvesting

Product Description

Product Parameters

Model		4LZ-6
Horsepower		109HP
Dimensions(L*W*H)(mm)		5860*2620*2930
Weight(kg)		3785
Cutting width (mm)		2300
Track	Track specification (mm)	90*53chains*500
	Track gauge(mm)	1250
Cab type		Awning or AC Cab
Production efficiency	Productivity(hm²/h)	0.3-1
	Fuel consumption(L/hm²)	≤41
	Mini clearance(mm)	300
Thresher	Grain tank(m³)	2.2
	Threshing pattern	Longitudinal axial flow
	Grain unloading drum height(mm)	3700
	Threshing drum size(mm)	Φ620*2200

Detailed Photos
4LZ-6 Our 4LZ-6 type crawler grain harvester, featuring advanced longitudinal axis flow roller threshing separation technology, is designed to effortlessly harvest rice and wheat. Additionally, it can be equipped with specialized devices to seamlessly handle rapeseed, corn, and millet harvesting, ensuring versatility and efficiency in all your crop harvesting needs.
Product Description
Technical Information on Model 4LZ-6
Optionally outfitted with a sophisticated plate-type divider and a 'mouse cage' divider, this machine boasts exceptional adaptability to a variety of crops. It is particularly effective for inclined crops, significantly reducing header losses. The spring gear tube comes with a protective cover designed to efficiently prevent grass entanglement, ensuring smoother operation. The design of the lifting and rotating header has been meticulously optimized. An extended bridge addresses issues with low-cutting headers (ideal for fallen crops) and high-point passability. The tip bottom of the header blade guard is a precise 40 mm below the horizontal ground, while the high point reaches 1000 mm from the horizontal ground. Enhanced with an optimized bridge feed inlet and floating wheels, this machine allows for adjustment according to the feeding amount, improving the passability of conveying. The bridge is equipped with a turn-over device, enabling quick resolution of blockage issues, ensuring uninterrupted operation. The grain separation chamber features a feed opening crafted from arc-shaped stainless steel, known for its superior strength and wear resistance. Featuring an efficient grain separation cleaning system, the grain roller extends to 2.0 meters. Equipped with a new-style cleaner fan and an adjustable-angle fish scale clean screen, it offers robust crop processing capabilities, systematically solving issues of poor feeding and high cleaning losses. The high-clearance chassis design provides a minimum ground clearance of 330 mm, enhancing resistance to sinking. Additionally, an option for chains further improves water field throughput and adaptability. Powered by a renowned high-quality National III engine, this harvester delivers strong power, high operational efficiency, and low fuel consumption. Integrated with the original imported hydraulic transmission and equipped with the 80 gearbox, this machine promises fast speed, flexible steering, and excellent maneuverability. The newly designed operator panel ensures unobtrusive and comfortable operation, adhering to human-machine engineering principles. Waterproof electrical components offer a long service life, with a recessed start switch to prevent accidental collisions or engine shutdowns. Offers two optional straw processing methods, making it highly versatile for different regional needs. Equipped with optional harvesting devices for rapeseed, corn, and millet, this machine demonstrates strong adaptability and multi-functional use.
Company Profile
Shandong King Machinery Co., Ltd. is a nationally recognized high-tech enterprise dedicated to the innovation, manufacturing, and global distribution of top-tier agricultural machinery. Our extensive product line includes pioneering corn harvesters, advanced grain combine harvesters, efficient soybean harvesters, reliable peanut harvesters, and robust rice harvesters. Additionally, we offer state-of-the-art tractors and a variety of essential agricultural auxiliary tools, ensuring comprehensive solutions for modern farming needs.
Spanning a vast area of 300,000 square meters and employing nearly 1,000 skilled professionals, Shandong King Machinery Co., Ltd. boasts 30 years of invaluable experience in agricultural machinery production. Our commitment to excellence has facilitated the export of our superior products to over 30 countries and regions, including Russia, South America, Central Asia, Southeast Asia, and Africa. With a remarkable portfolio of more than 70 scientific and technological invention patents, we excel in management and R&D, consistently innovating and tailoring designs to meet customer demands. Our dedication to outstanding product quality, independent R&D prowess, and exceptional after-sales service has garnered widespread acclaim from both domestic and international clients. Embracing the ethos of 'Serve customers and make progress together,' we remain resolute in our mission to advance the agricultural machinery sector. Our future efforts will focus on delivering superior products and services to farmers worldwide, enhancing planting efficiency, and solidifying our position as a trailblazer and leader in agricultural machinery research, development, and manufacturing-truly the KING of agricultural machinery.
Cutting-edge technology underpins the superior quality of our products
A wide array of choices to cater to the diverse needs of our customers
Our highly skilled technical team delivers prompt and professional technical support

Our Advantages
What dominates the market is not merely price,
but exceptional quality.
What truly resonates with people is not just words,
but unwavering integrity.
What retains customers is not simply discounts,
but powerful word of mouth.
Certifications
EXCEPTIONAL TECHNOLOGY DELIVERS COMPLETE SATISFACTION
Our confidence stems from our cutting-edge technology

---
