Features
1. Digital control, MCU technology, automatic parameter saving, IGBT inverter technology.
2. High frequency to guarantee lighter and smaller welder with higher efficiency.
3. Multi-function design wo meet various welding demands. It is suitable for DC TIG welding, MMA welding, spot welding, pulse TIG welding, etc.
4. Simple-to-use operator interface.
5. Less spatter, stable arc and good shaping.
6. Compete with TIG torch, electrode holder, earth clamp, face mask, hammer.
Technical Specifications
ITEM
| UNIT
| TIG-200P AC/DC
|
Input Power Voltage
| V
| AC230V±10%
|
Input Power Frequency
| Hz
| 50/60
|
Input Current
| A
| 31
|
Rated Input Capacity
| KVA
| 7.1
|
Output Current Range (TIG)
| A
| 5-200
|
Output Current Range (MMA)
| A
| 10-160
|
Pre-flow Time
| S
| 0.1-10
|
Post-flow Time
| S
| 0.5-15
|
Down Slope
| S
| 0-15
|
Balance
|
| 15-85
|
Arc Starting
|
| HF
|
AC Frequency
|
| 20-250
|
Pulse Frequency
|
| 0.2-200
|
No-load Voltage
| V
| 56
|
Rated Duty Cycle
| 35%
| 200
|
Rated Duty Cycle
| 60%
| 129
|
| 100%
| 100
|
Electrode Diameter
| mm
| 1.5-4.0
|
Efficiency
| %
| 85
|
Protection Grade
|
| IP22S
|
Insulation Grade
|
| B
|
Dimensions
| MM
| 440*210*360
|
weight
| Kg
| 11
|
