Lifting Tool Hydraulic Track Toe Jack 5 Ton Claw Jack

US$14.60
10-49 Pieces
US$13.40
50-199 Pieces
US$11.90
200+ Pieces

Basic Info.

Model NO.
5 ton
Type
Bottle Jack
Structure
Hydraulic Jack
Capacity (Load)
1-10T
Power Source
Hydraulic
Max Height
151-200mm
Certification
CE, ISO 9001:2008
Condition
New
Usage
Lifting Car or Other
Use Area
Vehicle Repair
MOQ
10 Sets
Color
Red or Customized
Material
Steel
Operation
Manual
Transport Package
Carton or as Request
Specification
1-100 ton
Trademark
Huiyu
Origin
Hebei, China
HS Code
8425421000
Production Capacity
5000 Peices /Month

Product Description

PRODUCT DETAILS Hydraulic Pro-Lift bottle jacks feature a steel lifting saddle cleated for load gripping power. Extension screw adjusts to accommodate work height. Patented bypass device protects against over-pumping. Heat-treated critical stress areas ensure long lift performance. Ideal for auto, truck service, farm, and shop use.
Bottle Jack Details & Function: 1. Easy for carry and widely used for car repair, workshop and outdoor, could help you a lot. 2. Capacity could from 2T, 4T, 6T, 8T to 100T, could use for all kindly of Car and machine. 3. Big loads easy to lift with high-quality. 4. Heat-treated saddle, large size base make the jack safer. 5. Factory tested for reliability and safety, Constructed of heavy duty steel.
Model
 Lifting
Wt(Ton)
 Min.
H(Mm)
 Lifting.
H(Mm)
 Adjust.
H(Mm)
 Max.
H(Mm)
 N.W
(Kg)
 Measurement
(Cm)
 Qty/Ctn
(Pcs)
 20'Container
(Pcs)
HY0202
2
 158
 90
 60
 308
 2.23
 52x25.5x19
 10
 7800
HY0402
3-4
 195
 125
 60
 380
 3.2
 46x26.5x22.5
 8
 5400
HY0602
5-6
 197
 125
 60
 382
 4,1
 38x27.5x22.5
 6
 4200
HY0802
8
 205
 125
 60
 390
 4.9
 29.5x27.5x22.5
 4
 3340
HY1002
10
 205
 125
 60
 390
 5.6
 30.5x29.5x24
 4
 3000
HY1202
12
 215
 125
 60
 400
 6.5
 30.5x16.5x24
 2
 2500
HY1502
15-16
 225
 140
 60
 425
 7.8
 31.5x17x24.5
 2
 2250
HY2002
20
 244
 145
 60
 449
 10.2
 34.5x19.5x27
 2
 1500
HY3202
30-32
 285
 180
 /
 465
 14.0
 37.5x19.5x31
 2
 1240
HY5002
50
 300
 180
 /
 480
 29.5
 26x24x33
 1
 540
HY10002
 100
 340
 180
 /
 520
 75.0
 32.5x26.5x36
 1
 240

Other kind of jacks are also available. If any request do not hesitate to let us know
