Four Shaft Shredder for Industrial Waste Plastic Barrel Scrap Metal Appliance Aluminum Cans Wood Chipper Cardboard Fabric

Product Description

Product Description Product Introduction
Four-shaft shredder is driven by four motors. Each shaft runs independently. Strong force and stable structure improve the efficiency of the production. Hard and wear-resistant alloy blade,40Cr axis,customized net screen to meet with the requirements of discharging size. Quadruple sealing, integral shredding chamber and Mitsubishi PLC automatic protection system, good brand reducers to ensure of the quality.
HLV has designed different ranges of four-shaft shredders for common applications with different components (reducers, blade sets, etc.) to guarantee a wide range of material adaptability. At the same time, we have the ability to custom-built machines to suit specific material and input/output requirements.


Which Materials can be Processed?
--- Plastic Waste: Plastic bottles, plastic jugs, plastic buckets, plastic baskets etc.
--- Electronic Waste: Old hard disk, PCB boards, lithium battery,keyboards, mice, mobile phones, CDs, etc.
--- Metal Waste: Iron filings, cans, paint buckets, thin metal materials, etc.
--- Medical Waste: Syringe waste, pharmaceutical waste, small medical devices, latex material waste, discarded masks
--- Paper Products: cartons, cardboard, newspapers, books, documents, brochures, wrapping paper, etc.
---Kitchen Waste: Fruit and vegetable waste, kitchen waste, farmer's market waste, etc. . . . . . . . .
Discharge Effect
Product Highlights
1.Alloy steel DC53 moving blade. Each blade can be rotated and reused four times;
2.Moving blade V-shaped arrangement. Two edge blades on th both ends of rotating shaft to prevent material side accumulation;
3. microcomputer (PLC) automatic control, set to start, stop, reverse and overload automatic reverse control.
4.Install shock absorbers to make them shred smoothly;
5. The device has a low speed, high torque, low noise, dust features can meet environmental standards.
6.Thickness and number of claw cutter knife can be replaced according to different materials.
Technical Data Technical Parameters

Model	Motor Power (kw)	Chamber Size (mm)	Main Rotor Diameter (mm)	Main Shaft (RPM)	Dimensions (mm)
HLF-800	2x11	800* 600	245	16-25	1950*1200*2000
HLF-1000	2x18.5	1000* 900	290	16-25	2300*1320*2000
HLF-1200	2x22	1200*1000	320	16-25	2810*1400*2700
HLF-1400	2x15+2x30	1400*1300	430	10-15	3600*1650*2900
HLF-1600	2x30+2x45	1600*1600	534	10-15	4360*2200*3600
...	...	...	...	...	...

Product Details

Packaging & Delivery
FAQ
Q:How long is your delivery time?
A:Generally, it will be about 35-40 days after deposit, which also will affected by the actual situation of the project.
Q:What Will We Do If We Have Problems in Machine Working After We Buy the Machine?
A: HANLV has people special for after-sale service,if customers outside China have problems when machine working,just feel free to send us the picture or video to show us,we will give you solutions in 24hours.
Q:Could We Visit Your Factory and Test the Machine?
A: We warmly welcome you to visit our factory anytime,and we are very glad to test our machine with your raw material.
Customer Feedback

Company Profile Company Profile
Hanlv is a new type of enterprise integrating R&D, manufacturing, sales and service of solid waste treatment equipment. In particular, it has extensive experience in metal recycling and plastic&wood &Tire crushing.
Hanlv has many years of experience in the solid waste recycling industry, and its equipment is sold in many countries around the world. Reliable equipment quality is our philosophy.
What do customers need?----This question has always kept us going.
Workshop View

Project Case
Contact us
We will be happy to advise you.

---
