Gantry Crane Seagull/OEM Wooden Case Lifting Equipment Plain Trolley with ISO9001: 2000

Negotiable 1 Piece (MOQ)

Basic Info.

Model NO.

GCT610

Application

Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane

Type

Electric Hoist

Sling Type

Wire Rope

Lift Speed

2~8m/min

Maximum Lifting Height

>20m

Certification

ISO9001:2000

Condition

New

Color

Orange

Packaging Details

Carton and Pallet

Supply Ability

10000 Sets Per Yea

Usage

Construction Hoist

Capacity

500kg to 5000kg

Transport Package

Wooden Case

Specification

0.25T-10T

Trademark

SEAGULL/OEM

Origin

China

HS Code

84251100

Production Capacity

50000 Units Per Year

Product Description

GCT610 Orange Chain Hoist Trolley , 10 Ton Manual Hoist Trolley
Product Details:
Place of Origin: CHINA
Brand Name: SEAGULL
Certification: GS/CE
Model Number: GCT610
Payment & Shipping Terms:
Minimum Order Quantity: 1 PCS
Price: Negotiation
Packaging Details: Packed in carton firstly,and then reinforced with steel case for outer packing
Delivery Time: 30 working days after received your payment
Supply Ability: 150000 pcs per year
DESCRIPTION:
*Capacity from 0.5T-30T.
*Wheels lubricated and equipped with bearings for long life.
*More thickness of the steel plates and strong shaft to ensure the good safety.
*The static test is 4times of capacity, and running test is 1.5times of capacity one by one
*One year warranty.

specifications	rated load(T)	test load(T)	Basic parameters				Recommended I-beams	net weight(kg)
specifications	rated load(T)	test load(T)	A	B	C	H	Recommended I-beams	net weight(kg)
0.5	0.5	0.75	271	172	190	108.5	75-125	8
1	1	1.5	271	206	222	122	75-125	12.5
1.5	1.5	2.25	308	231	238.5	130	100-150	15
2	2	3	308	240	267	132.5	100-150	16.5
3	3	4.5	342	279	319	181	100-150	23
5	5	7.5	384	318	384	219	125-175	37
10	10	15	442	380	490	275	125-180	68
