Compact Horizontal Metal Cutting Machine

Product Description

Company Profile
Product Description
Compact Horizontal Metal Cutting Machine
Explore our VMC series for precise 3/4/5-axis metal cutting. Ideal for CNC milling, drilling, and machining tasks. Enhance your industrial operations with our efficient cutting solutions.
Vmc550 650 850 1160 1270 1370 1160 1890 OEM ODM High Quality Vmc3 axis 4 Axis 5 Axis Universal CNC Vertical Horizontal CNC Machining Center Machining BT40 BT50 4 5 axis cnc milling machine manufacturer vertical machining center pirce AJMTG Most Popular 3 axis VMC CNC Vertical Machining Center
Nantong AJ Industry Limited offers the AJMTG CNC vertical machining center, an economic and heavy-duty CNC machining center suitable for various applications. With a motor power of 5.5 kW or higher and a spindle taper of BT40 or customizable, this VMC machine can handle workpieces up to 500kgs. It features precision construction with automatic lubrication, ball screws with special bearings for accuracy control, and a reinforced structure for shockproof performance.
The high-speed spindle unit and AC servo motor ensure low noise, minimal vibration, and efficient milling, drilling, reaming, boring, and tapping capabilities. Servo drive shafts on all three axes, a servo spindle with rigid tapping function, and options for Taiwan spindle, ball screw, and bearing enhance machining accuracy. The machine also offers X/Y/Z linear guide ways, a 10000rpm spindle speed, a portable hand wheel, and customization options for color, voltage, and logo.
For top-quality CNC machining with reliable after-sales service, choose the AJMTG CNC vertical machining center from Nantong AJ Industry Limited.
Product Parameters

Machining range	X axis travel	800mm
	Y axis travel	500mm
	Z axis travel	500mm
	Spindle nose to worktable	150-650mm
	Spindle to column guide	550mm
Worktable	Worktable size	1000x500mm
	T slot	18X5X90mm
	Weight load	500kgs
Spindle specification	Spindle	8000rpm belt drive Japan make
	Spindle motor	7.5kw
	Spindle taper	BT40(Ø140)
Feed system	G00 fast feed	48/48/36m/min
	G01 cutting feed	1-10000mm/min
	Servo motor	2*2*3kw
Tool system	Capacity	24 tools arm type Taiwan make
Main parts		Make
Ball screw		Taiwan C3 grade diameter 40mm, pitch 12/16mm
Linear guide		Taiwan HIWIN or Germany 35mm pin roller type
Spindle		Taiwan diameter 140mm , 8000 rpm
Tool magazine		Taiwan BT40-24 tools arm type
Bearing for 3 axis		Germany or Japan Nachi, Screw Angle Support Bearing 30X62

Our Advantages
Export Certificate for Nantong AJ Industry Limited's Compact Horizontal Metal Cutting Machine. Precision industrial equipment for efficient metal cutting.

---
