| Model No. | 8000STD |
| Generator Set | Rated Frequency | HZ | 50 | 60 |
| Prime Power | KVA | 5.5 | 6.5 |
| KW | 5.5 | 6.5 |
| Standby Power | KVA | 6 | 7 |
| KW | 6 | 7 |
| Rated Voltage | V | 115/230 | 120/240 |
| Rated Current | A | 47.8/23.9 | 56.5/28.3 |
| Rated Speed | r/min | 3000 | 3600 |
| Control Panel |
| Smartgen 4010 Display |
| Output | Socket |
| No |
| Terminal |
| Yes |
| Noise( at 7m) | dB(A) | 58 |
| Machine Size | mm | 700×500×560 |
| Machine Weight | kg | 150 |
| Alternator | Alternator Model |
| YP8000STD |
| Number of Poles |
| 4 |
| Phase |
| Single |
| Excitation Method |
| Brushing self excitation constant voltage (With AVR) |
| Power Factor | COSΦ | 1 |
| Insulation level |
| F |
| Diesel Engine | Model |
| YDM80S |
| Engine Type |
| Single cylinder inline, four stroke, direct injection, water-cooled |
| Bore×Stroke | mm | 92×75 |
| Displacement | L | 0.499 |
| Compression Ratio |
| 19.5∶1 |
| Rated Power | KW | 7.6 | 8.6 |
| Cooling water volume(engine only) | L | 4 |
| Lubrication method |
| Pressure Splash Composite |
| Oil No. |
| CD grade or above,SAE 10W-30、15W-40 |
| Oil Tank Volume | L | 1.65 |
| Start Method |
| 12V Electric |
| Volume of Start Alternator | V-KW | 12V 1.2KW |
| Fuel Consumption | g/KW.h | 298 |
| Fuel No. |
| Diesel: 0#(Summer)-10#(Winter)-35#(Severe cold) |
