| Product Model | Super Maker SLA300 | Material | 355nm photosenstiive resin materials |
| Laser type | Diode Pumped Solid State UV Laser | Vertical repeat positioning accuracy | ±0.002mm |
| Wavelength | Customized 355nm | Horizontal repeat positioning accuracy | ±0.001mm |
| Laser Power | 3W | Maximum production part weight | 45kg |
| Coating method | Automatic vacuum adsorption coating | Operating system | Win7 (32Bit) |
| Printing layer thickness | 0.05-0.15mm | Operating Software | ZH6.0 |
| Recommended printing layer thickness | 0.1mm | Import file format | SLC,STL |
| Material volume | 95Kg | Spot diameter | 0.1-0.2 mm |
| Maximum molding volume | 300×300×300mm (Customizable) | Recommended part scanning speed | 6000mm/s |
| Reference production weight | 50-180g/h | Recommended jumping speed of parts | 1200mm/s |
| Power Supply Parameters | 220V/50Hz | Working temperature | 20-28ºC |
| Relative humidity of working environment | <40% | Equipment size (W*D*H) Meter | 720*770*1730MM. |
| Network Type | Ethernet | Equipment weight | Around 350kg (Without materials) |
| Site Requirements (W*D*H) | ≥3M*3M*2.8M | ||
| Printing accuracy | Set the theoretical dimensions of the measured part of the part L:Part size <100mm:L±0.1mmPart size ≥100mm:L±0.1%×L*(The actual accuracy of the parts will vary due to factors such as printing parameters, part geometry, dimensions, materials, andenvironment. ) | ||
