| Engine | |
| Model | Kubota D1703 18.5KW/2200rpm |
| Max. Turque | 97.4N.m/1500RPM |
| Type | In-line, water cooled, Mechanical pump, normally aspirated |
| Displacement | 1.647L |
| No. of cylinder | 4 |
| Main performance | |
| Swing Speed | 0-11r/min |
| Traveling Speed(high/low) | 4.4/2.4km/h |
| Grade ability | 58% |
| Max. Bucket Digging Force | 30.4KN |
| Arm Digging Force | 18.2KN |
| Ground Pressure | 32KPA |
| Hydraulic system pressure | 22.5Mpa |
| Machine Weight | 3810kg |
| Boom Length | 2535mm |
| Arm Length | 1400mm |
| Fuel Tank capacity | 42L |
| Hydraulic Tank capacity | 48.5L |
| Engine oil capacity | 7L |
| Overall dimension | |
| Overall Length | 4915mm |
| Overall Width | 1720mm |
| Overall Height | 2525mm |
| Mini Ground clearance | 295mm |
| Track width | 300mm |
| Length of track | 2154mm |
| Track Gauge | 1420mm |
| Swing radius at tail | 860mm |
| Swing radius at front | 2538mm |
| Height of blade | 350mm |
| Operation parameter | |
| Bucket Capacity | 0.12 |
| Max. Digging Radius | 5480mm |
| Max. Digging Depth | 3208mm |
| Max. Digging Height | 4800mm |
| Max. Dumping Height | 3406mm |
| Max. vertical digging depth | 3208mm |
