Industrial Equipment Condition Online Wired Monitoring System 8 Vibration and Temperature Integration

Product Description

KMWG series wired monitoring station is used for online monitoring of industrial on-site machine,together with wired sensor they form the core of the monitoring system.It supports access to multiple types of sensors,such as vibration aceleration,vi-bration and temperature sensors,RPM sensors,etc.It also supports synchronous data collection of each channel,and is partic-ularly suitable for condition monitoring and precise fault diagnosis of rotating machine.High-performance signal collection capability to ensure data accuracy, using 24-bit A/D sampling, the highest sampling rate can reach 102.4KSPS, vibration + temperature + RPl synchronous collection.
Flexible data acquisition capabilitysuitable for a variety of collection scenarios, supporting various collection schemes such as timing/ temporary collection, keyphase synchronous collection, speed trigger collection, etc.
Abiity to access multiple sensors, supporting vibration sensorsvibration and temperature sensors, high-freguency resonance sensors, RPM sensors and other sensor types.

Type KMWG-Y16 KMWG-Y8
Vibration temperature measurement	Channels	16 vibration and temperature integration		8 vibration and temperature integration
	Connectable sensor types	ICP Acceleration		ICP Acceleration
	Maximum sampling frequency	102.4kHz		102,4kHz
	Maximum analysis frequency	40kHz		40kHz
	AD conversion	24-bit		24-bit
	Dynamic Range	110db		110db
	Data collection length	1K,2K,4K,8K,16K,32K.64K.128K		1K,2K,4K,8K,16K, 32K,64K,128K
RPM key phase measurement	Channels	2-channel		1-channel
	RPM range	6~30000RPM		6~30000RPM
Communication interface	Ethernet	1		1
	RS485	1		1
Power	power	AC 220V		AC 220V
Construction	Dimension	420*350*120mm		420*350*120mm
	Weight	13kg		13kg
Environment	Operating temperature	-40ºC~+70ºC		-40ºC~+70ºC
	Storage temperature	40ºC~+85ºC		-40ºC~+85ºC
	Humidity	Maxiuen5il		(a coudensation)
	Safety	CE
	Protection	IP66

MODEL	CARTON	ACQUISITION UNIT
KMWG-Y16	420X350X120MM	210X153X35MM
KMWG-Y08	420X350X120MM	210X153X35MM

Dimension
Company ProfileCold Valley Intelligent Technology (Shanghai) Co., Ltd. is a distinguished member of the prestigious Hanshan (Cold Mountain) Intelligent Technology Co., an elite enterprise dedicated to innovation and excellence.
(hereinafter referred to as Hanshan Intelligent Technology Co., Ltd. group) proudly commenced its operations in the bustling metropolis of Shanghai in 2013, marking a new era in technological advancement.
The founding team, comprised of veterans from world-leading automation giants, boasts an impressive collective experience: over two decades in the automation industry, coupled with more than 20 years in automation engineering, and a decade's worth of expertise in consulting and implementing cutting-edge digital solutions. Their mission is clear: to deliver top-tier automation and digitization products and services that cater to a global clientele. Strategically headquartered in Shanghai, China, the company stands as a beacon of technological prowess.
With a rich legacy spanning over two decades in the petrochemical sector, the company possesses unparalleled insights into the automation and digitalization demands across the industry spectrum-upstream, midstream, and downstream. They offer professional-grade products and comprehensive solutions, meticulously curated for the petroleum, chemical, electric power, biomedicine, APIs, food and beverage, liquor, metallurgy, and non-ferrous metal industries, ensuring full life-cycle service excellence.
You may have these questions
How do I select the right product?
A: Upon receiving your inquiry, our comprehensive technical dossier will provide all the necessary insights. This documentation will enable you to thoroughly verify the process parameters and technical specifications pertinent to your needs. With this information, we will expertly recommend the model that precisely aligns with your specific requirements.
I would like a confirmed model. Can you provide that?
A: Certainly. Once you communicate the model you are interested in, we will conduct a thorough verification process to ensure its suitability. If there are opportunities for cost-effective enhancements, we will gladly offer optimization suggestions. After your confirmation, we will proceed with crafting a formal quotation, tailored to meet your objectives.

---
