Kebida Brand Kbd3980 High Speed Precision Auto Part Car Lamp

Product Description

Product Description
Product Parameters

SPECIFICATION ITEM		KBD3980
Injection unit	Unit	A	B	C
SCREW DIA	mm	65	70	75
SHOT VOLUME (THEORETICAL)	cm3	1193	1393	1599
INJECTION WEIGHT(PS)	g	1098	1250	1455
INJECTION PRESSURE	Mpa	210	170	130
SCREW SPEED	rpm	0-150
CLAMPING UNIT
CLAMPING FORCE	KN	3980
TOGGLE STROKE	mm	740
SPACE BETWEEN TIE BARS	mm	730*730
MAX.MOLD HEIGHT	mm	780
Min.MOLD HEIGHT	mm	250
EJECTOR STROKE	mm	150
EJECTOR TONNAGE	KN	79
OTHERS
PUMP MOTER POWER	Kw	40
HEATING POWER	Kw	25.2
MACHINE DIMENSION(L*W*H)	m	7.5*1.95*2.4
MACHINE WEIGHT	T	19

FAQ
Q:How to choose injection molding machine?
A:The injection weight should be about 1.2× product's weight; The tie bar space should be bigger than the mold dimension; Contact with us for more information.

Q:How to pay?
A:40% deposit T/T in advance, the balance 60% payment by T/T before delivery (we accept payment by T/T, L/C etc.)

Q:Is that possible for your company to send engineer to install machine for commissioning, even train our workers?
A:Yes, we can send our engineer to your factory for installing, commissioning, training. We have some engineers flying among different countries for after sale service and technical support. As per experience, if everything OK usually 5-15 days is enough. Therefore, before shipment, we need you to prepare invitation letter for visa. However, please be noted that all cost happened for visa, travel, hotel should be paid in advance by customers. In addition, we cannot guarantee each visa is successful.

Q:If we buy your machines, is there any warranty?
A:Yes, definitely. Totally 24-months warranty after shipment for mechanical parts, hydraulic parts, electric components (The screw just has 6-months). We are responsible for broken parts within 24-months. We will supply those parts in freeway but the possible transportation cost should be paid by clients.

Q:What is different with A,B,C screw, What is the price different?
A:The screw model is designed for different material and requirements, the screw diameter Changes from small, middle and big. There is no price difference in the price for choosing A/B/C screw types.

Q:How to choose the screw ?
A:For PC,Pa(Nylon)and other high viscosity material ,it's better to choose A screw .
For PP,PE,PS materials, better to choose B Screw .
For Recycled material , better to choose C screw .

Q:What's the delivery preriod after place the order?
A:Normally the delivery date will be in one month after receiving the down payment .

---
