| Model | SUNON PRO 3.5K | SUNON PRO 5.5K |
| The rated power | 3500VA/3500W | 5500VA/5500W |
| | INPUT |
| Voltage | 230 VAC |
| Selectable Voltage Range | 170-280VAC(UPS), 90-280VAC(Appliances) |
| Frequnecy Range | 50Hz/60Hz (Auto sensing) |
| | OutPUT |
| AC Voltage Regulatlon (Batt.Model) | 230VAC + 5% |
| Surge Power | 7000VA | 11000VA |
| Efficlency(Peak) | >90% |
| Transfer Tlme | 10MS(UPS),20MS(Appliances) |
| Wave form | Pure sine wave |
| No load current | 1.0A | 1.1A |
| | Battery |
| Battery voltage | 24VDC | 48VDC |
| Low battery alarming voltage | 22.0VDC | 44.0VDC |
| Low battery cut off protectlonvoltage | 21VDC | 42VDC |
| Low battery recovery voltage | 23.0VDC | 46.0VDC |
| Floating Charge Voltage | 27VDC | 54VDC |
| Overcharge Protectlon | 23VDC | 64VDC |
| | Mppt Solar Charger& AC Charger |
| Maxlmum PV Array Power | 5000W | 6000W |
| MPPT Range at Operatlon Vol | 120-450VDC |
| Maxlmum PV Array Open CircultVol. | 500VDC |
| Number of MPPT trackers / Max output current | 100A |
| Maxlmum AC Charge Current | 100A |
| Maxmum Charge Current | 100A |
| Maxmum Efficlency | 98% |
| | Best Panel Configuration |
| Best Panel configuratlon | 300Wp*9pcs*36V(2700Wp)*2Parallel | 330Wp*9pcs*36V(2970Wp)*2Parallel |
| | Physical |
| Products Dlmenslon, D*W*H(mm) | 481mm*313mm*117mm | 481mm*313mm*117mm |
| Packlng slze, D*W*H(mm) | 543mm*394mm*204mm | 543mm*394mm*204mm |
| Net Welght (kgs) | 9.8KG | 10.5KG |
G.W. kg
| 11KG | 11.7KG |
As a world-class solar products manufacturer, Sunpal specializes in the research, development, production, and sales of solar PV products and half cut solar panels. Sunpal is accredited as Batch I Smart Manufacturing Plant by Jiangsu Government, the Witness Laboratory Accreditation Certificate (WMTC) by CSA,DEKRA, and CTF Laboratory Certificate by TUV SUD. Sunpal focused on research and manufacture of solar panels since the year 1998, we have exported our various kinds of full-black solar panels to 86 countries and won a good reputation in quality. With over 10 years of development, Sunpal now has factory area covering 150,000 square meters, with 600 experienced employees. Details Imagine
