Product Description
Product Description
ApplicationBench-Top Wet Spinning MachineAT235 Bench-top Wet Spinning Machine is special design for researching new material in the field of textile, macromolecule and other material. It consists of spinning solution tank, dosing pump, gooseneck, spinneret, coagulating bath, drawing roller, heating slot, drawing roller, setting slot, drawing roller and winding roller.Details and Features★ Manual lifting platform to move the spinning solution tank, dosing pump, gooseneck and spinneret up or down together;★316L stainless steel gooseneck and coagulating bath;★ Coagulating bath with two filament pressing rollers and optional heating system;★ Optional heating system for coagulating bath;★ Heating slot adopts non-touch air heating;★ Nylon drafting rollers with adjustable rotation speed;★ The whole line adopt quick joint connecting, it’s easy to assemble;★ It can simulate the whole process;★ Mini size, save space;Technical specificationModelAT235Spinning solution tank1L or customized316L stainless steelRapid-mount coverWith Nitrogen inlet port and vent portSample volume200~ 600ml or customizedDosing pump flow rate0.66CC/revDosing pump power180WDosing pump reducer1:59Gooseneck material316L stainless steelNo. of spinneret1Spinneret nut100 holes, hole dia.: 0.07mmMaterial: tantalumCoagulating bathInner size1000×160×160mm (L×W×H)Material316L stainless steelDrawing rollerMaterialNylonSizeØ50×80mmReducer1:5Motor power120WRoller speed3~40m/min adjustableHeating bathTypenon-contactLength400mmHeating power250WTemp. rangeRoom temperature~150℃SensorPT100Setting bathTypenon-contactLength(400×2)mmHeating power250W×2Temp. rangeRoom temperature~150℃SensorPT100WinderSpeed3~40m/minSizeØ95×80mmTransverse displacement60mmThe Whole line length4200mmPower supplyAC220 50Hz, single-phaseOur CompanyPacking & DeliveryPakegingpakeging Details1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated.Contacting UsTitle goes here.Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding MachinePET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.Title goes here.Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding MachinePET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.Title goes here.Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding MachinePET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
>>
