Fiberglass Direcct Woven Roving Filament in 2400tex, ECR Glass

Product Description

Fiberglass Direct roving for Woven Roving
1200TEX

Test Item	Testing Method	Standard	Test Result	Conclusion
FILANENT DIAMETER	ISO1888	16±1um	16.5	pass
(Tex) ROVING LINEAR DENSITY	ISO1889	1200±60	1217	pass
(% )MOISTURE CONTENT	ISO3344	≤0.1	0.04	pass
(%) LOSS ON IGNITION	ISO3344	0.55±0.15	0.56	pass
NET WEIGHT PER DOFF		≥10kg	18.7	pass
BREAKING STRENGTH	GB/T7689.5-2001	≥0.4	0.43	pass
APPEARANCE				pass
REFERENCE STANDARD	GB/T18369---2001

2400TEX

Test Item	Testing Method	Standard	Test Result	Conclusion
(tex) Roving Density	ISO1889	2400±120	2364	pass
(%) Moisture Content	ISO3344	≤0.1	0.03	pass
(%) Loss on Ignition	ISO1887	0.55±0.15	0.60	pass
(μm) Filament Diameter	ISO1888	22±1	22.2	pass
(N/tex) Tensile Strength	ISO3341	≥0.30	0.42	pass
Glass Type	GB/T 1549	ECR	--	pass
Size Type	--	Silan e	--	pass
APPEARANCE				pass
Reference Standard	GB/T18369---2008

4800TEX

Test Item	Testing Method	Standard	Test Result	Conclusion
(tex) Roving Density	ISO1889	4800±240	4778	pass
(%) Moisture Content	ISO3344	≤0.1	0.03	pass
(%) Loss on Ignition	ISO1887	0.50±0.15	0.64	pass
(μm) Filament Diameter	ISO1888	25±1.0	25.2	pass
(N/tex) Tensile Strength	ISO3341	≥0.30	0.45	pass
Glass Type	GB/T 1549	ECR	--	pass
Size Type	--	Silan e	--	pass
APPEARANCE				pass
Reference Standard	GB/T18369---2008

Packing:
Net Bobbin Weight: 15-19KG (or upon customer's request).
Pallet Weight: 3*4 or 4*4 Bobbins each layer, 4 layers each pallet. Each layer can be connected to the under layer according to customers request.
Each bobbin is protected by film. Each Pallet is wrapped by stretch film.
