Offgrid 2000W 3000W Smart PV Solar Inverter 12V 24V DC to AC 220V 2kw 3kw Pure Sine Wave Power Inverter for Solar System

Product Description

Offgrid 2000W 3000W Smart PV Solar Inverter 12V 24V DC to AC 220V 2KW 3KW Pure Sine Wave Power Inverter for Solar System
Features 1.Pure sine wave solar inverter
2.Output power factor 1.0
3.Built-in 80A MPPT solar charge controller
4.Selectable input voltage range for home appliances and personal computers.
5.Wifi & GPRS available for IOS and android
6.Compatible to mains voltage or generator power
7.High PV input voltage range(50-430VDC)
8.Built-in anti-dust fit for harsh enviroment
9.Compatible with lithium battery and lead-acid battery
10.Smart battery charger design for optimized battery performance
This 3200W pure sine wave inverter is a new all-in-one hybrid solar charge inverter, which integrates solar energy storage & means charging energy storage and AC sine wave output. With 80A MPPT solar charge controller, using the latest optimized MPPT technology, efficiency up to 98%.Hybrid Solar Inverter Max.PV Input Power: 3000W, Voltage range: 50-430Vdc, Max. PV Input VOC: 450V DC, Starting voltage >50V;Recommended PV cable size: 16AWG, Max.charge current: 80A. Nominal Input Frequency: 50/60Hz; Output Power: 3000W, Surge Capacity: 6400VA.Off Grid Solar Inverter have 4 charging modes are optional, i.e. Only Solar, Mains Frist , Solar Frist and Mains & Solar hybrid charging;and 3 output modes are available, i.e. Solar Frist, Mains Frist and SBU Priority, uninterrupted power supply to meet different application requirements. And compatible to mains voltage or generator power, Auto restart while AC is recovering.MPPT Inverter Charger Pure sine Wave 3200W for RV Camping Boat Home Emergency ect.. Can be accessed to a variety of household and office loads, including Oven, rice cooker, lamps, televisions, fans and other AC loads.(Be careful not to install it near the bedroom, the fan will make a sound when the inverter is running.Avoid affecting your rest (expect 50-70 db).
Product Parameters

Model NO.		VOL-LI-2000VA-12V		VOL-LI-3200VA-24V
Rated Power		1600W		3000W
INPUT	Phase&waveform	230 VAC
	Voltage selectable range	170~280 VAC(for Personal Computer)
	Voltage selectable range	90~280 VAC(for home appliance)
	Frequency range	50Hz/60Hz (Auto sensing)
OUTPUT	AC voltage Regulation(Batt.Mode)	230V AC ± 5%
	Surge Power	4000VA		6400VA
	Efficiency (Peak) PV to INV	98%
	Efficiency (Peak) Batt. to INV	94%
	Transfer time	10ms (for personal computer),20ms (for home appliance)
	Wave form	Pure sine wave
Battery& AC Charger	Battery voltage	24VDC		48VDC
	Floating charge Voltage	27VDC		54VDC
	Overcharge Protection	33VDC		63VDC
	Maximum Charge Current	60A
PV Input	Charge current	80A
	MPPT Range @ Operating Voltage	50-430VDC
Physical	Inverter Dimension, D×W×H (mm)	350*259*90		350*259*90
	Package Dimension,D×W×H (mm)	423*348*172		423*348*172
	Net/Gross Weight (Kgs)	4.6/5.6		4.8/5.8
Environmental	Humidity	5%~95% Relative Humidity (Non-condensing)
	Operation Temperature	0ºC~55ºC
	Storage Temperature	-15ºC~60ºC

01	Communication Port	07	Ground Wire
02	LCD Display	08	Battery Input
03	Function Buttons	09	PV Input
04	AC Input	10	ON/OFF Switch
05	AC Output	11	Ventilation Holes
06	Ventilation Holes

FEATURES
*Integrated MPPT charge controller
*Equalization charging function Work with battery or without battery
*Maximum PV input voltage up to 430VDC
*Configurable grid or solar input priority
*Optional WiFi/GPRS remote monitoring
*PV and Grid power the load jointly if PV energy unsufficient
*Flexibly schedule the inverter charging and discharging time
Q1.Are you a manufacturer?
A1: Yes, we are professional and experienced manufacturer with our own R&D research center.
Q2.How about quality of products?
A2: All of our product already get pass the aging test, to ensure reliability of using,and without having to worry about quality.Our products may not be the lowest in price, but I promise that our prices definitely matches its quality. we are on higher level than the ones that seize more market by low cost.
Q3:How can I get the price list of your product?
A3:Please feel free to send us an email here and you will get our reply within 12 hours.
Q4.How to place an order?
A4: Contact with online service, or sent email to us directly, we will reply to you with product price, specifications, packing etc. soon.
Q5.Can I visit your factory?
A5: Yes, welcome to visit our factory at your convenient time.
Q6.How can I make OEM or ODM orders?
A6: We welcome OEM/ODM orders.Please contact us with online service or send email to us directly.
Q7:Can I get a sample before bulk order?
A7:Yes,we welcome sample order to test and check the product quality.Mixed samples are acceptable.
Q8:When the product have problem,how to solve it?
A8:With guaranteed product quality all of our items are tested by using precision electronic instruments before packing and delivery to clients.In case of any problems,please contact us immediately.We have a 24 months warranty and lifetime technical support.We will track product usage until you are satisfied.
Tips: There are many low-cost solar power inverter is actually some assembled small unlicensed workshops, it crudely, to reduce costs and use of substandard components for assembly, there is a very big security risk! In order to protect the pro personal and property safety, please do not covet low price, be sure to choose a reliable inverter!

---
