9500lbs Pulling Electric Powered Anchor Winch with Wire Rope

US$182.00-202.00 15 Pieces (MOQ)

Basic Info.

Model NO.
A9500
Pull Direction
Forward
Electric Winch Model
off Road
Working Voltage of Electric Winch
Low Voltage
Brand
Zhme
Applicable Environment
off Road
Certification
CE, SGS
Item
E9500
Rated Pull
9500lbs(4310kg)
Power
12V DC
out Put
5.5HP/4.0kw
Gear Ratio
262:1
Brake
Automatic Brake System
Transport Package
Carton and Pallet
Specification
9500 winch
Trademark
ZHME
Origin
China
HS Code
84253190
Production Capacity
10000PCS/Month

Product Description

9500lbs pulling electric powered anchor winch with wire rope
Advantage:
1. Motor: High performance series wound motor, powerful and waterproof.
2. Brake: Automatic brake system.
3. Solenoid: 500A waterproof solenoid in control box.
4. Gear: 3-Stage planetary gear made of 20CrMnTi material, hard enough and reduce speed perfect.
5. waterproof: ZHME patent double lips seals ensure IP68 waterproof of motor and gear box.
Winch Specifications:
ANT9500
Rated Line pull: 9500lbs (4310kgs)single line
Motor: Series wound 5.5hp/4.0kw,12V DC
Gear Train: 3stage planetary
Gear Ratio: 218.:1
Clutch: Sliding ring gear
Braking Action: Automatic in the drum
Wire Rope: 7.8mm×28m
Synthetic Rope: 9.5mmX26m
Drum Size: 2.5"×9.0"(63mm×226mm)
Dimensions: 21.5"×6.3"×7.6"(545mm×160mm×194mm)
Mounting Bolt Pattern: 10"×4.5"(254mm×114.3mm)
Battery: 650 CCA minimum for winching 25 mm2,72"(1.83m)
N.W: 37kgs
Packing: 620mm×360mm×260mm(420pcs/20'container)

ZHME owns more than 15000m2 factory including 150 works and 150m2 showing room, and with technical department which is in charge of research and development, improving products.
ZHME has own die casting workshop which can die cast winch support, gear box, aluminum fairlead and other accessories, CNC center which can process winch parts such as support, gear box, fairlead, etc..
ZHME has own auto assembling line where can assembly more than 500pcs winches every day, there is also testing facilities to test motor, solenoid, winch pull, speed and electric current.
