> 1000W CE Approved Bstabo Iron Frame and 2350X1278X1400 mm UTV Electric ATV

Product Description

Product Description BSTABO 2024 new two seat 2WD/4WD 12KW 4 wheel electric ATV quad All terrain vehicle with 110Ah battery.
Product Parameters

Model Name	Rock 12Pro
DIMENSIONS
Overall Vehicle Size (L x W x H)	92.5 x50.3 x55 in(2350x1278x1400 mm)
Wheelbase	57.5 in (1460 mm)
Ground Clearance	11.8 in(300 mm)
Seat Height	35.4in(900 mm)
Person Capacity	2
Max. Power	22.8HP(17kw)
Max. Speed	>70km/h
Max. Wheel Torque	1923N·m
Estimated Dry Weight	992lb(450kg)
Payload Capacity	540lb(245kg)
Climbing Capacity	40°
Drive System Type	2WD/4WD
Towing Capacity	1500lb(680kg)
CHASSIS
Steering	EPS
Brakes	Hydraulic Disc Brake
Parking Brake	Lockable Handle, Mechanical Parking Brake
Front Suspension	Dual A-Arm Independent Suspension
Rear Suspension	Dual A-Arm Independent Suspension, With Balance Bar
Shock Absorber Type	Adjustable Hydraulic/Gas
Differential lock	Front Differential Lock
Wheels	14 in. (35.6 cm)Aluminum
Front Tires	27 x 9-14
Rear Tires	27 x 11-14
ELECTRICAL SYSTEM
Instrument Panel	5in TFT
Lights	LED headlights,LED taillights
BATTERY PACK
Rated Voltage	144V
Battery Core Material	Ternary Lithium
BMS	√
Battery Capacity	110Ah
Charging Time	1.65h(20%-80%)
Estimated Range	120km
ELECTRICAL MOTOR
Motor Type	Permanent Magnet Synchronous Motor
Rated Power	12kw
Mas. torque	136N·m

Company Profile Bstabo Power Technology (Wuxi) Co., Ltd. was established in 2020, operating under its own brand "BSTABO." As a global all-terrain vehicle company, BSTABO is dedicated to providing reliable and high-quality electric all-terrain vehicle products to users worldwide.
BSTABO's brand slogan is "Make Exploration More Natural." The company strives to create joyful and passionate outdoor experiences for users, promoting a green, eco-friendly, and technology-driven lifestyle that brings people closer to nature and allows them to enjoy outdoor living.
