Light Gauge Steel Frame Machine Forming Machine China Famous Brand

Product Description

Light gauge steel framing systems consist of structural frames fabricated using cold formed steel sections. They can be used throughout a structure, including load-bearing exterior walls, non-load bearing interior walls, floor joists, curtain walls and roof trusses.The system automatically generates wall and floor fabrication drawings, structural layouts, cut lists and other material reports.By automating these processes, manufacturers save a lot of time in drafting, material reporting, data entry, manufacturing, and correcting all errors.
We offer a complete range of machines for light gauge steel framing. Simply provide the profile, thickness, or any specific requirements you have, and we will provide you with customized solutions.

Top Selling	Cheap Discount	Adjustable Multiple Profile
Suitable for 1-3 floors building	Suitable for beginners	Suitable for multiple floor building

Producing Process Flow

Profile Dimensions
Profiles can be designed according to customers requirements

Project	Yield Strength (MPa)	Thickness (mm)	Width (mm)	Surface Treatment
C63-200	Q300-Q550	0.75-1.6 mm	152-300 mm	Galvanized / Galvalume / Zinc-Aluminum-Magnesium coated

Real Customer FeedbackReal Customer's Project
Light gauge steel framing machines are used to create the structural framework of buildings by cold forming steel sections into columns, beams, studs, tracks, and joists. These machines can be used in a variety of applications, including:residential and commercial construction,Prefab and modular house, warehouses and manufacturing facilities etc.
Machine Picture
Technical Parameters

Item	Details
Model	C63-200
Equipment Size	8600x1300x1600 mm
Equipment Weight	Approx. 10T
Forming Method	16 groups + Shaping
Transmission Method	Gear + Sprocket drive
Main Motor	20.5kW Servo Motor
Rollers	Material: SKD11 die steel
Main Shaft	Material: 40Cr
Forming Speed	2700m/hour (excluding punching & cutting)
Production Capacity	4-4.5T/8 hours (average speed)
Hole Distance Tolerance	±0.5mm
Nail Hole Height Error	≤0.5mm
Length Tolerance	±0.75mm

Machine Components

No.	Items	Quantity
1	Steel Strip Uncoiler	1
2	Roll Former Machine	1
3	Hydraulic Puncher/Cutter	21
4	Hydraulic Station	1
5	Design Software	1
6	Controlling System	1
7	Label Printer	1
8	Layout Table	1

Service
1. Factory Lifetime Service:offer technical support for the entire life of our machines.
2. Customized Profile:can design the profile according to customer request.
3. One-Year Guarantee Period:we could supply you the replacement parts free of charge for any damaged parts caused by quality problems.
4. Overseas Services Optional:we can send our technicians to install and train the workers in the clients' factories with extra cost.
Shipping
For different machines or production line parts, we have different packing solutions:
- For the machine or production line, we will use plastic film to cover and wrap. Then will be loaded to the container by forklift or crane.
- For the key parts such as the roll forming rollers set, we will use the metal frame to package.
All Steadily fastened in the container in a suitable manner with steel ropes and locks, being suitable for long-distance transportation.
Our Factory
XIAMEN XINHONGHUA MACHINERY CO. LTD.(FUJIAN XINHONGHUA MACHINERY CO. LTD) was founded in 2004.as the earlier company which engaged in the manufacture of cold roll forming machines,after the reform and innovation of more than 19 years,and on basis of manufacture of modern management concepts,strong technology,advanced production technology,perfect service system,we have been currently in the domestic leading position,and as good competitor among the same industry of world. Our company is located in the beautiful scenery,nice island of Xiamen.And have variety of products with stable performance,Always pay attention to improve the existing products and research and develop the new products.We have nearly 100 kinds of professional and technical personnel,with its strong ability of product design and development,to ensure a high level design of our product.For our products with light structure, reasonable design and updating styles,so we become well-know in the steel structure industry.

---
