High Speed HDPE LDPE PE Poly Plastic Nylon Rubber Polypropylene Film PP Film Blowing Machine Blown Film Extrusion Machine Extruder Blowing Machine

Product Description

The Polypropylene (PP) plastic film blowing machine is designed to produce plastic films of various thicknesses, widths, and lengths. Polypropylene (PP) film are widely used in various industries for a variety of applications. PP films are highly versatile and can be produced with various properties such as thickness, clarity, strength, and flexibility, making them suitable for many different uses. Some common uses of PP films include:
Packaging: PP films are used for packaging a range of products, such as food, cosmetics, and pharmaceuticals. The films provide protection against moisture, air, and light, which helps to preserve the product's quality and freshness.
Construction: PP films are used in construction for vapor barriers, roofing membranes, and insulation. The films provide a barrier against moisture and help to improve energy efficiency.
Electrical: PP films are used in electrical applications for insulation, capacitors, and flexible printed circuits.
Machine Features
1. The PP film blowing machine is suitable for producing PP. It is widely used for packing food, garment, textile, daily necessaries and industrial product.
2. Die head can be turned in 360, it can strengthen the tension and evenness degree of film.
3. Screw and cylinder are all made of 38CrMoAl alloy, and treated by nitrogen. It has an advantage of great thickness, corrosion resistance and endurance.
4. Die head has been chromized, it's advantage of screw core structure, melting material extruding evenly, and blowing film smoothing.
5. Cooling equipment is a labyrinth blow pump, which has good effect. Especially it adopts the recycling cooling water system to ensure the best transparent effect.
6. Discharging equipment adopts pressing braking winding equipment and central winding equipment, and it adopts torque motor to adjust, has the merits of smooth film, convenience operation.
Our PP film blowing extruder is easy to operate, energy-efficient, and capable of producing films with high optical clarity and mechanical strength. It is able to handle a wide range of plastic materials, including low-density polyethylene (LDPE), high-density polyethylene (HDPE), and linear low-density polyethylene (LLDPE).Polypropylene (PP)
With a reliable PP blown film machine, our machine can meet customers' production goals with ease and produce high-quality plastic films that meet their customers' expectations.
Optional Equipment:
1. Auto-loader
2. Corona treater
3. Rotary die head
4.Double winder
5. Air compressor
6. High speed screen changer

Model	XG-PP50	XG-PP55	XG-PP60
Suitable material	HDPE/LDPE/LLDPE/PP
Film width	100-600mm	100-700mm	100-800mm
Film thickness	0.006mm-0.10mm(if you have special request please clarify)
Max.Output capacity(kg/hr)	30kg	38kg	45kg
Screw diameter(mm)	50mm	55mm	60mmm
Screw L/D Ratio:	30:1	30:1	30:1
Driving motor(kw)	11	15kw	22kw
Screw material	Full bimetallic	Full bimetallic	Full bimetallic
Barrel material	38CRMOALA	38CRMOALA	38CRMOALA
Cylinder cooling	250wx1	250wx1	250wx2
Temperature control(zone)	7	7	8
Die head size(mm)	220mm	260mm	350mm
Air blower(kw)	1.1	1.1	1.1
Roller width(mm)	700	800	900
Take up speed(m/min)	10-60	10-60	10-60
Take up motor(kw)	1.5	1.5	1.5
Winding motor(N/M)	6	6	6
Winding speed(m/min)	10-60	10-60	10-60

Production procedure
Sample film
Machine outlook
Rewinding part
Control frame part
Machine extruder part
Control box
Package and container loading
Our service Team
Factory layout
