RC Single Hydraulic Cylinder Lifting Jack

Product Description

RC single hydraulic cylinder
1.It has the characteristic of low collapsed height,if the requirement of stroke needs to be higher than RMC series,RC series is suit for this case.
2.The surface of principle axis is finished with chrome plate to protect the using of longeity of the products..
3.Plunger has the function of retracting automatically WRC rotary head,can work in bevel.
Model RSC-1050 RSC-2050 RSC-3050 RSC-5050 RSC-10050

Tonnage	10T	20T	30T	50T	100T
Stroke	50mm	50mm	50mm	50mm	50mm
Cylinder Effective area	11.3cm²	22cm²	31.1cm²	56.7cm²	95cm²
Collapsed Height	96mm	98mm	104mm	104mm	136mm
Extended Height	146mm	148mm	154mm	154mm	186mm
Outside Dia. (mm)	62mm	88mm	105mm	128mm	175mm
Cylinder Bore Dia.	45mm	65mm	75mm	95mm	130mm
Thread for input oil-port(ZG)	3/8″-19	3/8″-19	3/8″-19	3/8″-19	3/8″-19
Weight	0.7KG	1.60KG	2.75KG	5.0KG	7.0KG

---
