PP PVC PET PE Plastic Film Label Paper Foam Fabric roll Slitting Rewinding Machine

Product Description

Product Description
PP PVC PET PE Plastic Film Label Paper Foam Fabric roll Slitting Rewinding Machine
Functional characteristics:
1.Microcomputer web guiding.
2.Magnetic powder control tension.
3.Frequency motor to control speed.
4.Air cylinder control the pulling roller up and down.
5.Laminating function.
6.8 rotary slitting blade can be adjusted.
7.Automatic meter count.
8.1 3inch inflatable unwind shaft and 2 3inch inflatable rewind shaft.
9.Air blower for trimming.
Purpose:
This machine can slit flexible materials,such as plastic,paper,foam,film,etc.

Main Technical Parameters:
Model DP-650DP-1300DP-1600
Max Feeding Width650mm1300mm1600mm
Minimum slitting width25mm25mm25mm
Rewinding Diameter600mm450mm450mm
Unwinding Diameter450mm600mm600mm
Precision ± 0.1mm± 0.1mm± 0.1mm
Voltage220V 50HZ380V 50HZ380V 50HZ

Product Pictures:
