LPG Mobile Station Diesel Storage Tanks Container Fuel Stations Cryogenic Gas Tank Gas Station Equipment LPG Storage Tank

US$8,000.00-30,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
CLW510LPG50P
Function
Storage Pressure Vessel
Application
Liquefied Gas
Material
Carbon Steel
Pressure
1.6MPa≤p<10.0MPa
Storage Medium
Flammable/Toxic
Pressure Level
Medium Pressure (1.6MPa≤p<10.0MPa)
Condition
New
Tank Purpose
Storing Liquid Propane/Ammonia/Butane Gas for Gas
Tanker Material
Q345r, 16mndr, Q370r, SA516gr70, SA517, etc.
Overall Size (Length X Width X Height)
5608*2224*2814 (mm)
Tank Diameter
DN2200mm, etc.
Tank Thickness
Shell 12mm, Head 14mm.
Tank Volume Options
5-200cbm; Usually 50m3 60m3 80m3 100m3 120m3
Tank Capacity Options
2ton-100ton; Usually 25ton, 30ton, 40ton, 50ton
Design Pressure
1.71MPa/17.1bar, 1.77MPa/17.7bar, 1.61MPa/16.1bar
Design Temperature
-20degree~50degree
Corrosion Allowance
1 mm
Color
as Per Customer′s Request
Life Time
20 Years
Transport Package
Naked Package, Bulk Ship, Roll-Roll
Specification
20cbm 20m3 20000Liter 20000L
Trademark
CLW
Origin
Suizhou, China
HS Code
73110090
Production Capacity
500 Unit/Month

Product Description

LPG MOBILE STATION Diesel Storage Tanks Container Stations Cryogenic Tank Gas Station Equipment lpg Storage Tank
Product Description
1. LPG Tank Storage Content: LPG Gas, Propane, Butane, Liquid Ammonia, etc.
2. Tank Design Standard: GB150-2013, ASME Standard with U STAMP.
3. Test: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.

Product Specification
Volume of Tank 20 CBM
Filling Weight 7980kg
Tank Weight 4820kg
Thickness of Shell (mm) 12 mm
Thickness of End plate (mm) 14 mm
Tank Diameter (mm) 2200 mm
External Dimensions (mm) (length x width x height) 5608 x 2224 x 2814 mm
Material of Tank and Main Pressure Parts Carbon Steel Q345R
Filling Medium Liquefied Petroleum Gas ( Propane)
Design Pressure 1.77 MPa
Test Pressure 2.22 Mpa
Corrosion Allowance 1 mm
Medium Density 420-590 kg/ cbm
Main parts of LPG Tank
Item Specification/ mm Quantity
Discharge Pipe DN50-2" 1
Inflow Pipe DN50-2" 1
Outlet DN50-2" 1
Gas phase balance pipes DN50-2" 1
Manhole DN450 1
Drain Hole DN50-2" 1

Reference Photos
We supply customized drawing for every storage tank
Nozzle data
Characters Size Pressure(MPa) Connect Junction surface Purpose
a DN50 25 HG20592-WN RF Drain outlet
b DN50 25 HG20592-WN RF Liquid phase outlet
c1-2 DN50 25 HG20592-WN RF Gaseous phase balanced outlet
d DN50 25 HG20592-WN RF Liquid inlet
e M33*2 Screw-thread Thermometer connection
f1-2 DN25 25 HG20592-WN RF Lever gauge connection
g M20*1.5 Screw-thread Pressure Gage
h DN100 25 HG20592-WN RF Safety valve connection
i DN50 25 HG20592-WN RF Emptying mouth
j DN450 25 HG20592-WN FM Manhole

Main Structure Diagram
We supply package solution for lpg station building as follows
