1734-Ssi Point I/O Ab Serial Synchronous Interface (SSI) Module Industrial PLC

Product Description

POINT I/O is a family of modular I/O products ideal for applications requiring flexibility and low cost of ownership. With one to eight channel density modules, including a self-configuring discrete module, the modularity of POINT I/O minimizes system costs and size. The ability to mix standard and safe I/O provides even greater flexibility and opportunities for standardization, regardless of application requirements. Since it can be used in local and remote I/O, POINT I/O further reduces engineering costs in design, installation and application development. As part of the Rockwell Automation Integrated Architecture, POINT I/O provides comprehensive channel-level diagnostics (wire off and short circuit), and configurable features, such as user-set filters and alarms, making it easy to use in your application. POINT I/O is the only IP20-rated modular I/O solution compliant with ODVA requirements for linear, star, and ring EtherNet/IP architectures. This provides you with greater system reliability and availability, maximizing your uptime and system performance. IO-Link is the first technology for communication with sensors and actuators to be adopted as an IEC 61131-9 standard. POINT IO-Link Master allows up to four IO-Link devices to be connected to the POINT I/O system. Regardless of the application, POINT I/O brings the power of the Integrated Architecture to the field device in a small, easy-to-use package.
Brand Part Number/Catalog No. Manufacturer: Series Module Type Product Description: SSI Channels Product Family Supply Voltage Part Number: POINTBus Current Supported Protocol Power Dissipation No of SSI channels Key Switch Position SSI Data Rate SSI Bits Per Word SSI Word Delay Time SSI Word Length SSI Features Supply current Operating Temperature Storage Temperature Relative Humidity

AB

1734-SSI

Rockwell Automation

POINT I/O

SSI Module

Serial Synchronous Interface (SSI) module

1

1734 POINT I/O

10-28.8 Volts DC

1734-SSI

110 milliamps

SSI

0.94 Watts

One (1) SSI port

2

125 kHz, 250 kHz, 500 kHz, 1 MHz, 2 MHz

2…31

16 µs…64 m

4 bytes (32 bits)

Gray or binary code capable with gray to binary conversion, increasing or decreasing SSI count indication, 2 SSI word comparator values, SSI word latching with I1 input SSI Position Forming Time(2) > 0.5 ms

110mA @ 24V dc

-20 to 55oC (-4 to 131oF)

-40 to 85 °C (-40 to 185 °F)

5% to 95% (non-condensing)

---
