Santana Full Vehicle Electrical Training System Automotive Training Equipment Vocational Training Educational Equipment

Product Description

Teaching Lab Equipment Training Models Complete Fault Setting System Product Introduction
The equipment is based on Volkswagen Santana all-vehicle electrical appliances, and fully demonstrates the composition structure and working process of Volkswagen Santana all-vehicle electrical appliances. It is suitable for the teaching needs of the theory and maintenance training of Volkswagen Santana all-vehicle electrical appliances in middle and higher vocational technical colleges, general education colleges and training institutions.

Main configuration
Volkswagen Jetta starter system, charging system, engine electronic control system, lighting system, instrument system, door and window system, wiper system, audio system, rearview mirror system, ignition switch, movable bench, universal caster with lock, etc. .

Features
1. A color inkjet circuit diagram is drawn on the measurement panel of the training platform. It is made of high-strength acrylic sheet with a thickness of 8mm. It is resistant to large temperature differences, wear-resistant, moisture-proof, corrosion-resistant, not easily deformed, has a long service life, and has bright colors. Not easy to fade and other characteristics.
2. The training platform expands the electrical equipment of the entire vehicle in a flat form. Each system is fixed according to the relative position of the original vehicle. The lines are clear and clear. It is consistent with the original vehicle system. The detection is convenient and the operation is simple.
3. There are detection terminals installed on the panel of the training platform, which can directly detect the electrical signals of various sensors and actuators on the panel, such as resistance, voltage, current, and frequency signals.
4. The training platform is built with international standard aluminum alloy profiles. It has the characteristics of light weight, high strength, corrosion resistance, long life, etc., without spraying process, it is more environmentally friendly, the appearance is more beautiful and high-grade, the platform has self-locking casters The device is flexible in movement, safe, reliable, durable.

Technical Parameters
1. Overall dimensions: 2400 × 800 × 1800mm (L × W × H)
2. Power supply: three-phase four-wire (three-phase five-wire 380V ± 10% 50Hz)
3. Input power; AC 220V ± 10% 50Hz
4. Working power supply; DC 12V

---
