Tractor Mounted Peanut Potato Carrot Garlic Beetroot Onion Harvester

Product Description

Product Description
Multipurpose walking tractor harvester
This machine is used in conjunction with a tractor and is mainly used for digging and harvesting underground fruits of sweet potatoes, potatoes, peanuts, garlic, and rhizome medicinal crops in clay and semi-sand soil.
This machine can complete excavation, soil and seedling separation, and crop laying operations at one time. It has:
1. Small loss rate: During the suitable harvest period, the loss rate is small
2. Clean soil and seedling separation: Due to the use of vibrating lifting conveyor chain, the soil and fruit seedlings are effectively separated after being pressed by the pressure roller.
3. High operating efficiency: Due to small operating resistance, fuel consumption is reduced, which improves operating efficiency and economic benefits.
4. Easy to install and adjust: The optimized design makes installation more convenient and use and adjustment simpler.
5. The rotating parts of the whole machine are made of high-quality bearings, which have reliable performance and small movement resistance, making the operation more stable.
Product Parameters

Model	Dimension (cm)	Matching power (kw)	Working width (cm)	Working efficency(hm2/h)	Weight (kg)
4H-80	180*95*100	13.3-20.7	80	0.07-0.21	230
4H-130	295*152*105	29.6-37	130	0.17-0.3	520
4H-150	300*168*105	33-40.5	150	0.26-0.35	550
4H-165	355*189*120	59.2-64	165	0.23-0.40	820
4H-180	345*206*112	51.4-73.5	180	0.3-0.45	900
4H-215	350*240*120	73.5-88	215	0.3-0.5	1080

Detailed Photos
Packaging & Shipping

---
