Welcome to visit

Cone Crusher Automatic Crusher for Construction Aggregate, Road Base Material

US$35,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
GP200
Crushing Capacity
100-500t/h
Type
Hydraulic Cone Crusher
Material
High Manganese Steel
Characteristic
Two Stage Crushing
Function
Stone Crusher
Leavel
High Level
Transport Package
Simple Packaging
Trademark
HW
Origin
China
Production Capacity
10000/PCS/Year

Packaging & Delivery

Package Size
500.00cm * 300.00cm * 200.00cm
Package Gross Weight
25000.000kg

Product Description

Company Profile
Hebei Hongwan Mining Machinery Factory was established in 1998 and is a large-scale mining
machinery manufacturing enterprise that integrates research and development, production, sales, and
after-sales service. Hebei Hongwan Machinery Manufacturing Co., Ltd. was officially registered and
established in 2018, engaged in production, sales, import and export business. Over the years, the company
has strengthened the introduction, digestion, and absorption of domestic and foreign technologies. The
company has strong technical strength, scientific management system, and excellent product quality, and
has developed into an important mining machinery production base in northern China.
The company's main products include HP series multi cylinder hydraulic cone crushers, GP (CH, CS) series
single cylinder hydraulic cone crushers, PE (C) series jaw crushers, sand making machines, impact crushers,
hammer crushers, YA series vibrating screens, linear vibrating screens, feeders, sand washing machines,
ball mills, magnetic separators, mobile crushing equipment, and over a hundred other products. There are
also technical researchers, testers, and a high-quality design, installation, and after-sales service team,
forming a service plan that integrates design, development, production, inspection, installation, debugging,
and after-sales service. Detailed Photos
Product Parameters
GP100 GP200S GP300S GP500S GP100 GP220 GP330 GP550
Power 75-90kw 110-160kw 132-250kw 200-355kw 75-90kw 132-220kw 250-315kw 250-400kw
Crusher dead weight 7350kg 10900kg 16200kg 33300kg 5800kg 10200kg 15700kg 26500kg
Feeding Port
Crushing
chamber
feeding port
EF 46mm 58mm 68mm
F 53mm 89mm 85mm 95mm
MF 95mm 101mm 107mm 113mm
M 206mm 141mm 118mm 135mm 152mm
C 239mm 222mm 247mm 321mm 142mm 182mm 184mm 192mm
EC 295mm 332mm 401mm 213mm 225mm 250mm
EC-LS/EC-TR 332mm 442mm 213mm 225mm 265mm
