160t 5X9FT Hot Press Machine for Laminating Veneer or Man-Made Board

Product Description

Using this hot press, you can make plywood laminating boards and honeycomb laminating boards used for fortunite or door. For door, it is only used for hot pressing thin man-made board and inner wood frame. You can alos laminate many kinds of small size decorative paper, decorative cloth, melamine fireproof board, nature and man-made veener, metail foil and something else on plywood, block board, fiber board and particleboard.

	BY215x9/16(3)H1RC
Total pressure	1600KN
Working layers	3
Max.pre.int. of valid working width	3.6kgf/cm2
Platen & size	4-3000x1500x42mm
Opening	120mm
Cylinder No. & diameter	10-Φ85mm
Heating way	electric heated with thermic oil
Platen open way	Automatically
Installation power	77.5kW
Closing speed	24mm/s
Overall size	4320x1920x2440mm
Gross weight	11500kg
Optional equipment	Relay/PLC control circuit

Features:
1.(1)Prevent the hot platen tilt;
(2)Prevent the hot platen deformation.
2.Electric controlling way:
(1)PLC control circuit;
(3)Relay control circuit.
3.Heating way:
(1)Electric heating with thermal oil;
(2)Steam exchanging heating thermal oil;
(3)Both heating with electric heating with thermal oil and steam heating;
(4)The user prepares the heating .
4.Hot platen protecting material :
(1)Mylar ;
(2)Thin S.S.platen ;
(3)Anti sticking PTFE cloth.
The press can be painted with the color according to the user.
Advantage:
1.It can lift the hot platen,close the separation,add the pressure,keep the pressure,keep time, descend the hot platen and so on.
2.As to the oil heater,it is adjustable,safe, uniform temperature,energy saving and so on.
3.Cylinder:It is worked through excellent CNC precision machine tool.
4.It uses high quality oil seals to make sure good sealing.
1.Delivery and Package:
-We will take care of your machinery packages well.
-Our workers will make sure your machine clean before package.
-We will add stretch film for the whole machine and spare parts for delicate protection.
-We will make export standard strong wooden box case package as your request for the knocked down parts of machines.
2.Guarantee:
The main machine is guarantee for 12 months and the electric elements is guaranteed for 6 months.Within guarantee under normal using and maintenance.If the machine has something problem because of our quality fault you will get spare part for free. After the guarantee, you will get the cost price for accessories.You will also get technical support and service all the time.
3.Technical Support:
-Technical support by Phone,Email,Wechat 24 hours online
-We provide English version manual.
-Engineer available to service machinery overseas.
4.After sales service:
Our machine is installed and tested well before delivery.You can operation the machine immediately after received machine.If you don't know how to use the machine,we will offer you cost training until you can use machine freely.And if there is still any question, please contact us by Email, Phone, and we chat online service at any time.

---
