| performance parameter | |
| Bucket capacity (m³) | 0.02 |
| Width of bucket (cm) | 40 |
| Bucket depth (cm) | 20 |
| Bucket excavator (KN) | 7.5 |
| Bucket rod support force | 15kn |
| Engine | Horizontal bar air-cooled diesel engine/motor |
| Engine power | 9.5kw/7.5kw |
| Walking speed | 1.8km/h |
| Rotary speed | 10rpm |
| Climbing angles | ＜45° |
| size | |
| Length x width x height | 2520x720x375 |
| Track length | 1142 |
| Track width | 150mm |
| Clearance from the ground | 80mm |
| Length of shovel | 715mm |
| Bulldozing shovel width | 17mm |
| Weight | 650kg |
| working range | |
| Mining height | 2350mm |
| Discharge height | 1600mm |
| Digging depth | 1350mm |
