| US$2.10-3.30 | 500 Pieces (MOQ) |
| Model: | YS12M-0502000 | YS12-0602000 | YS12-0751500 | YS12-0901300 | YS12-1201000 | YS12-2400500 | ||||
| Power: | 12W Max | |||||||||
| Input: | AC100-240V | |||||||||
| Output Voltage: | 5V DC | 6V DC | 7.5V DC | 9V DC | 12V DC | 24V DC | ||||
| Output Current: | 2A | 2A | 1.5A | 1.3A | 1A | 0.5A | ||||
| Inrush Current: | 65 Amps max. at 230VAC/50Hz,full load | |||||||||
| Leakage Current: | <50μA | |||||||||
| Protections: | Short Circuit /Over Current /Over Voltage/Over temperature protection | |||||||||
| Withstand voltage: | I/P-O/P 4kVAC | |||||||||
| Working TEMP.: | -20°C-50°C | |||||||||
| EMC standards: | EN55011 class B,EN61000-3-2,3 EN61000-4-2,3,4,5,6,8,11, EN61204-3, EN60601-1-2 medical level,FCC Part 15 class B, EAC TP TC 020 | |||||||||
| Safety standards: | ANSI/AAMI ES60601-1/ES60601-1-11,CAN/CSA-C22,TUV EN60601-1-11,EAC TP TC 004 approved | |||||||||
| Dimension: | 69*27*38mm | |||||||||
