High Frequency Wood Frame Jointing Machine

Product Description

High Frequency Precision Frame Assembly Machine
1.Introduction:
High Frequency Precision Frame Assembly Machine is updated system for high precision miter door assembling. CNC system is integrated with high frequency technology.
2.Features:
1. Servo motor, ball screw, and linear guide rail can make sure the high quality of assembling (diagonal tolerance is less than 0.5mm).
2. High frequency technology only heats glue line without wood, which can help customer save the time (5-15 seconds can finish one door assembly) and electricity (Each frame costs is less than 0.06KWh).
3. HF Precision Frame Assembly Machine is controlled by PLC automatically. Easy to learn and convenient to operate. It is the best choice for wooden door, PVC wrapped door assembly such as photo frame, cabinet door, closet door, as well as other kinds frame and doors.
4. Machine is multi-functional, which can also assemble 90 degree and 135 degree corner frame with or without tenon.
3.Parameters:

Model	HFPM-1880-LD	HFPM-2880-LD
Max. Working size	1800x800mm	2800x800mm
Min. Working size	150x150mm	150x150mm
CNC	Servo Motor+ ball screw+linear guide rail
Output power	5KW	5KW
Overall size	3000x1150x1800mm	4000x1200x1800mm
Weight	1000kg	1200kg

---
